TTI QL II Series Service Manual page 27

MECHANICAL ITEMS - QL355T & QL355TP UNPACKED PARTS LIST continued/...
Part No. Description
33533-0430 LENS - DISPLAY - QL
33533-0440 WINDOW - DISPLAY - QL
33536-4303 COVER PAINTED QL TRIPLE GREY3
33536-4360 CHASSIS - PRINTED QL TRIPLE
33536-4840 CHASSIS - PRINTED QL TRIPLE P
37113-2113 BUTTON 6.5D X 9.4L GREY3
37151-0533 KNOB 32MM (QL) D-SHAFT GREY3
37541-1230 LABEL SAFETY EARTH GRN/WHITE
43187-2030 WIRE SET CUT BASIC nQL UL
43187-2040 WIRE SET CUT QL-T UL
43187-2050 WIRE SET CUT QL-P UL
43187-2060 WIRE SET CUT QL-T r/TERMS UL
44117-0020 PCB ASSY - CONTROL - QL355
44117-0070 PCB ASSY - TERMINAL - QL355 U
44117-0090 PCB ASSY - KEYBOARD -QL355T U
44117-0130 PCB ASSY IEC 230V QL355T/TP
44117-0180 PCB ASSY - POWER - nQL355
44117-0210 PCB ASSY AUX TERM/POWER nQLT
44117-0220 PCB ASSY LAN/USB/232/GPIB
47511-0010-L KEYPAD - QLT LEFT
47511-0010-R KEYPAD - QLT RIGHT
FIXINGS AND FASTENERS QL355T/TP QL564T/TP
Part No. Description
20010-0254 RIVET SNAP-LOCK 4.1D X 5.5T
20010-0264 RIVET SNAPLOK 3.6Dx2.2-3TGREY
20010-0266 RIVET SNAP-LOCK 3.6Dx2-3H F/HD
20030-0266 WASHER M4 ZPST
20030-0271 WASHER M4x12x1 ZPST
20037-0304 WASHER M4 SHK/PROOF I/T ZPST
20037-0310 WASHER WIDE RIM 4.3IDx12.6OD
20062-9301 SCREW No.4x3/8in. Pozi. Pan
20063-0010 SCREW NO6 X 3/8 NIBHDPZ ST/AB
20063-0020 SCREW NO6 X 1/2 NIBHDPZ ST/AB
20065-0070 SCREW M2.5 X 6 PLAS PNHDPZ
20210-0110 NUT M4 BARB
20210-0111 NUT M4 SERRATED FLANGE
26
Position
FRONT PANEL
Position
Fan
Chassis/Fan bracket
Power pcb/Fan bracket
Earth terminals
Output terminals
Front feet(2), Terminals(8)
Earth terminals
GPIB bracket
Case
TX
K/B/FP(6), Handle bracket(4)
Terminals
Earth
