Error Codes

Three enclosure elements are assigned a unique, two digit element ID number (see
Table D–2) for error code purposes. IDs that are part of the error code format as explained
in this section.
Table D–2 Element ID Numbers
Active IDs
02.01.–02.02.
03.01.–03.03.
0.7.01.
All other IDs reserved for future use.

Error Display Timing

Error codes are displayed for a minimum of 15 seconds from the time the error is reported
or until the error is corrected, allowing the user time to identify the problem. Each alarm
report initiates the 15 second time out, ensuring that when there are multiple errors or a
recurring error, the code is displayed. The complete alarm report is stored and can be
recalled using a combination of the increment and the group switches.

Error Code Format

The alphanumeric display error condition displays are in the format
CRU Type Element Number Error Code.
cooling air for Fan 2.
NOTE: The periods in the display identify the error display level.
The CRU type display has a period after each digit.
The element number display has a period after the second digit.
The error code display has no periods.
Enclosure Element
Power supplies
Fans
EMU
For example, 0.3. 02. 04 indicates an insufficient
