B
Appendix

Enclosure Specifications

This appendix defines the physical, electrical, and environmental specifications for the
Compaq StorageWorks Model 2100 and 2200 Ultra SCSI controller enclosures (shown in
Figure B–1 and Figure B–2, respectively).
CXO6321D CXO7235A
Figure B–1. Model 2100 controller enclosure
