Cleaning
Water Tank
1. Remove the water tank, as described earlier, and put into the sink and empty the
water.
2. Using the supplied brush, gently run the inside surfaces of the cap, paying particular
attention to the rubber ring in the outer groove and the centre rubber seal.
3. Put a small quantity of washing liquid into the tank, refit the cap and shake well,
then rinse out until all traces of wasking liquid are gone.
4. Refill with filtered tap water only, replace the cap, ensuring to not over tighten.
Sump
1. Press the 'On' button to put the product into standby.
2. Gently lift out the fuel bed and place carefully on the ground.
3. Remove the water tank by lifting upwards.
4. Remove the sump lid to allow the sump to be lifted completely from its location
(Fig 5).
5. Carefully tilt so that the liquid drains out of the sump.
6. Put a small amount of washing liquid into the sump, and using the supplied brush,
gently clean all surfaces including the metal disc (Fig 9).
7. When cleaned, thoroughly rinse the sump with clean water.
8. Clean the outlet surface of the sump lid with the brush and flush out thoroughly
with water.
9. Reverse the above steps to reassemble.
Air Filter
1. Press the 'On' button on the remote control or manually to switch off.
2. Gently lift off the fuel bed and set aside.
3. Remove the tank and place in a sink with the cap facing upwards.
4. Gently slide up the air filter (Fig 10).
5. Gently rinse with water in the sink and dry with a fabric towel before returning.
6. Replace the filter making sure that the course black filter is in contact with the
plastic holder.
7. Replace the tank.
8. Replace the fuel bed.
9. Press the 'On' button to turn on the product.
15
