INTERFACING SOLUTIONS
CADILLAC
2014 - 2015 ATS
2013 - 2015 CTS
2013 - 2015 SRX
CHEVROLET
2014 - 2015 Corvette
2015 - 2015 Colorado
2014 - 2015 Silverado
2015 - 2015 Tahoe
GMC
2014 - 2015 Sierra
2015 - 2015 Suburban
2015 - 2015 Terrain
PARTS INCLUDED
(1) GM-94M Interface Module
(1) GM-94M 6-Pin Harness
(1) Instruction Sheet
TECH SERVICES
All our products are manufactured under strict quality control. Each device is being tested before shipment. If nevertheless do occur problems or if
you have technical questions, contact us directly:
Crux Interfacing Solutions Tech Support
1 (855) 822-1348 (Mon - Fri - 9:00 AM - 5:00 PM) Pacific Time
Rev. 091814
VIDEO IN-MOTION INTEGRATION
FOR SELECT CHEVROLET, CADILLAC
& GMC VEHICLES 2013-UP
SAFETY PRECAUTIONS
1. Please read through the entire instruction manual before starting any of the installation procedures.
2. We recommend disconnecting the negative side of the battery until ready to code the vehicle.
3. Do not install any of the main modules near any major components or near the HVAC system,
as placing items near the HVAC may cause damage or overheating to the vehicle or interface.
4. We recommend not disconnecting any of the air bag connections behind the dash panels.
5. This product is under Crux's 1 year manufacturer's warranty. Warranty may be voided in the case where
the device shows proof of being opened or improper extreme force.
1
VIMGM-94M
APPLICATION NOTES:
WORKS FOR:
MyLink + CUE Radios
This interface does not offer the
Force RVC feature.
Contact Tech Support for more
information.
www.cruxinterfacing.com
Advertisement
Related Manuals for Crux VIMGM-94M
Summary of Contents for Crux VIMGM-94M
- Page 1 4. We recommend not disconnecting any of the air bag connections behind the dash panels. 5. This product is under Crux’s 1 year manufacturer’s warranty. Warranty may be voided in the case where the device shows proof of being opened or improper extreme force.
- Page 2 VIMGM-94M VIDEO IN-MOTION INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS INSTALLATION OVERVIEW STATUS LED’S CUT PIN 4 TO INTERCEPT THE DATA 8-PIN (male plug) YELLOW/RADIO SIDE CUT WIRE YELLOW/BLACK/CAR SIDE RED/12V CONSTANT CAR SIDE LIGHT GREEN/DATA BLACK/GROUND Rev.
- Page 3 VIMGM-94M VIDEO IN-MOTION INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS CONNECTING THE INTERFACE Follow these steps to properly install the interface module. Step 1 - Remove the RADIO panel to gain access to the factory 20-PIN Harnesses. You will need to locate the CAN wire on the vehicle.
- Page 4 VIMGM-94M VIDEO IN-MOTION INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS CONNECTING THE INTERFACE Follow these steps to properly install the interface module. Step 3 - Use the facotry 20-PIN connector to tap for DATA. Normally the 20-Pin connector will be GRAY and the CAN wire is located on PIN 4 of the factory connector.
-
Page 5: Dip Switch Description
VIMGM-94M VIDEO IN-MOTION INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS CONNECTING YOUR DEVICES TO THE INTERFACE Follow these steps to properly install the interface module. Step 5 -The power for the module can be found on the GREEN 16-PIN connector. Located next to the GRAY connector. - Page 6 VIMGM-94M VIDEO IN-MOTION INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS TESTING THE INTERFACE Make sure to test the interface while the vehicle is in motion. Step 1 - Use the features on the factory display to test the interface module. Using the VIDEO source will be your fastest way to test the interface.
- Page 7 VIMGM-94M REAR-VIEW CAMERA INTEGRATION FOR SELECT CHEVROLET, CADILLAC & GMC VEHICLES 2013-UP INTERFACING SOLUTIONS COMPATIBLE RADIOS: MyLink + CUE Radios 7” Rev. 091814 www.cruxinterfacing.com...
