5
A
Lay the printer down on its side, electronic compartment facing down. Remove the
six screws (A-F). Replace screws E and F with the M4x16 screws supplied with the
installation kit.
6
Put the printer back on its feet. Remove the four screws that hold the cover to the
center section. Gently pull out the cover so the console cable can be disconnected
from the CPU board.
RFID Kit (Gen 2, 869/915 MHz) Installation Instructions
E
B
D
C
F
5
