6. Appendix

6.1 Discharge Voltage - Current curve

Sample 12V battery cell
Status From fully Charged (100%) to protection (20%)
X axis Discharging current (A)
Y axis Discharging voltage (V)
Remark This figure represents theoretical values which are only for reference. The battery life
varies upon the actual charging and discharging currents.
TBB5 discharge voltage - current curve
35
30
25
20
15
10
5
0
0A 0.5 1A 1.5 2A 2.5 3A 3.5 4A 4.5 5A 5.5 6A 6.5 7A 7.5 8A 8.5 9A 9.5 10A
Version B March 2019
TBB5 User Manual
Output Voltage
