2. Specifications

Model name
Battery capacity
Input
Output
Duty cycle
Operation temperature
IP rating
Dimension
Net weight/pc
ON/OFF switches
Battery cell
Version B March 2019
TBB5
4.0Ah (0.1C-discharge by 400mA)
30VDC (29-45VDC)
25.6VDC, 4.0A (Max. 10A)
10% (2 min on / 18 min off)
0 - 40
Up to IP66W (optional)
209 * 116 * 60 mm
1.6kg
With
Lithium iron phosphate (LiFePO4)
