Summary of Contents for Timotion TBB6
- Page 1 VERSION: C 20200514 TBB6 USER MANUAL...
-
Page 2: Table Of Contents
TBB6 User MANUAL Contents Contents ..................................2 1. Warning ................................3 2. Specifications ..............................4 3. Operation ................................5 4. Indications ................................5 Status ......................................5 Table ......................................5 Remarks ....................................5 5. Protection ................................6 6. Maintenance................................. 6 Storage ...................................... 6 Repair ...................................... -
Page 3: Warning
TBB6 User MANUAL 1. Warning Must follow the rated input voltage Don’t discard or expose the products into water or heat source Recycle with certified depots Repair by authorized maintenance centers Version C May 2020... -
Page 4: Specifications
TBB6 User MANUAL 2. Specifications Model name TBB6 5.0Ah 2.9Ah Battery capacity (0.1C discharging, 500mA) (0.1C discharging, 290mA) Input 29~45V DC Output 24VDC, 5.0A 24VDC, 2.9A Duty cycle 10% (2 min on / 18 min off) Operation temperature 5~45 IP rating... -
Page 5: Operation
TBB6 User MANUAL 3. Operation When there is no AC-in Button Operation Action Press>1 sec Turned on and discharging Press>3 sec Turned off and stop discharging 4. Indications 4.1 Status Process Status When charged Hi charging Charging Discharging Hi battery... -
Page 6: Protection
TBB6 User MANUAL 5. Protection Under below protection status- LED continuous off Protection type When Lasting for Discharge- Over current protect Current > 10.0A 10 sec Discharge- Low voltage protect Voltage <16.0VDC 15 sec Standby - Low voltage protect Voltage <22.5VDC 10 min 6. -
Page 7: Appendix
Discharge current (A) Y axis Discharge time (min) Remark In real situation the discharge varies- this test is only for reference TBB6 and TBB7 (5.0Ah) discharge time curve Time (min) TBB6 and TBB7 (2.9Ah) discharge time curve Time (min) Version C May 2020... -
Page 8: Cycle Test Curve
Charge until max capacity 500mA 290mA reference *Repeat since 51 times TBB6 and TBB7 (5.0Ah) cycle test curve Max capacity (Ah) TBB6 and TBB7 (2.9Ah) cycle test curve Max capacity (Ah) Version C May 2020...
