Path Chair Disassembly Instructions
Tools Required
Safety Glasses Flat Screwdriver Sheet Metal Screw
Adjustable Arm
Remove Arm Pad Assembly from Arm
1a
Nylon
Step 1a
GF
On adjustable arm, use a flat bladed screwdriver to pry
out cover as shown (will remove pin with the cover).
Step 1b
For Fixed arm, use a smaller sheet metal screw to lock
into hole shown and then pull out the pin.
Glass Filled Nylon
GF
Step 2
Lift up on rear of arm pad and slide forwards to
2
Fixed Arm
remove.
This completes fixed arm disassembly. Arm pad
components on the fixed arm assembly do not easily
separate from the nylon structure. See next page to
continue adjustable arm disassembly.
1b
Steel
Glass Filled Nylon
GF
Some components may not be recyclable in your area. REV-00
