Path Chair
Tools Required
Remove Internal Components from Mechanism
Step 1
Use a T-30 Torx bit to remove 7 screws from housing
This will allow removal of the axle cap, LH & RH seat
Ramps, height actuation lever and spring retainers
(these must be pried up from aluminum housing and
away from connector to remove).
Step 2
Remove (2) bumpers from axle cap.
Some components may not be recyclable in your area.
Disassembly Instructions
Safety Glasses Flat Screwdriver T-30 Torx Bit
Steel
1
Height Actuation Lever
Glass Filled Nylon
GF
Ramps
POM
>POM<
Spring Retainer 2X
Nylon
GF
POM
>POM<
Bumpers
TPE
>TPE<
Axle Cap
Aluminum
REV-00
