Path Chair
Tools Required
Remove Seat Slide Lock System
Step 1
Pry up tab (identified with arrow) on seat slide
release using a flat bladed screwdriver and push
inward. It will pop free of the structure.
Step 2
Unhook spring from structure and seat slide release.
Step 3
Push lock plate inwards to remove a spring
underneath it. Remove both.
Some components may not be recyclable in your area.
Disassembly Instructions
Safety Glasses Flat Screwdriver
Glass Filled Nylon
GF
3
Lock Plate
POM
>POM<
Seat Slide
Glass Filled Nylon
Spring
Steel
2
1
REV-00
