Shimano ALFINE Inter-11 Dealer's Manual page 26

INSTALLATION
Installation of the shifting cable
(A)
5
(B)
(A)
6
Screw in the inner hole cap as shown in
the illustration until it stops.
If it is turned any further, it will damage
the screw thread in the cover.
In addition, the unit cover may become
bent, which may cause an obstruction
between the unit cover and the main
lever, and the main lever may not
operate correctly.
If the main lever does not return
(C)
properly, loosen the inner hole cap
slightly to make a gap between the main
lever and the unit cover, and check that
this improves the returning of the main
lever.
Pass the inner cable through the OT-SP41
(z)
outer casing through the end with the
plastic cap.
(z)
(B)
Lever side
26
(A)
Inner hole cap
(B)
Unit cover
(C)
Main lever
Tightening torque
0.3 - 0.5 N·m
(A)
Aluminum cap
(B)
Plastic cap
TECH TIPS
If cutting the outer casing, cut it near the end
with the plastic cap while the cap is still
attached.
Then make the cut end perfectly round and
attach the plastic cap.
Plastic cap
Remove the plastic cap
Make the cut end perfectly round.
Attach the plastic cap
