Summarization of Contents
Installation
Installation of the sprocket to the hub
Procedure for installing the sprocket onto the bicycle hub, including applicable sprockets.
Installation of the CS-S500 sprocket with chain guard
Steps for attaching the CS-S500 sprocket and chain guard to the hub.
Installation of the cassette joint to the hub
Instructions for mounting the cassette joint pulley and bracket onto the hub driver.
Installation of the disc brake rotor
Guide for installing the disc brake rotor onto the hub, including tightening torque.
Installation of the hub to the frame
Steps for mounting the hub onto the bicycle frame, including non-turn washer placement.
Installation of the shift lever
Procedure for mounting the shift lever onto the handlebar.
Installation of the shifting cable (Internal 8-speed)
Steps for routing and securing the shifting cable for internal 8-speed hubs.
Installation of the shifting cable (Internal 11-speed)
Steps for routing and securing the shifting cable for internal 11-speed hubs.
Adjustment
Adjusting the cassette joint (Internal 8-speed)
Procedure for aligning setting lines on the cassette joint bracket and pulley for 8-speed hubs.
Adjusting the cassette joint (Internal 11-speed)
Steps to align yellow setting lines on cassette joint for 11-speed hubs.
Maintenance
Replacement and assembly of the indicator unit
Instructions for removing and reinstalling the indicator unit on bicycle hubs.
Internal 8-speed oil maintenance
Safety information and handling precautions for WB maintenance oil for internal 8-speed hubs.
Internal 11-speed oil maintenance
Safety information and handling precautions for SG-S700 OIL for internal 11-speed hubs.
