UG-169
2
USING I C SERIAL PORT MODE
2
Figure 3. I C Address Jumper Setting
1. Select the desired I
(see Figure 3). Note that setting P5 and P6 low is reserved
for SPI mode.
2. On the evaluation software, select Configure Serial Port
from the I/O menu (see the I/O Menu section).
3. Click the Reset Serial Port button, and then click Detect
Current Configuration (see Figure 8). A dialog box
should appear to acknowledge the I
Rev. 0 | Page 4 of 12
Evaluation Board User Guide
2
C address using Jumpers P5 and P6
2
C mode and address.
