Artecta Indalo A0244024 Product Sheet

T A
HE RT OF
A0244024 Indalo Strip-18 RGB 40x12°
The Indalo Strip-18 RGB is a compact and robust exterior lighting fixture,
suitable for a wide range of wall-washing and accent lighting applications.
The sleek and modern design of this fixture allow for exellent integration into
most kinds of archtecture. Used in conjunction with the Indalo Drive-4, the
Indalo Strip-18 RGB is an extremely flexible lighting tool.

Technical specifications:

LED system: RGB, 6xRed, 6xGreen, 6xBlue
Optics: 40x12°
Power consumption: max. 33W
Lumen output: 100% Red 369 Lm
100% Green 450 Lm
100% Blue 98 Lm
100% R+G+B 837 Lm
Peak intensity: 2176cd
Housing: Die cast Aluminium, off-white powder coated
Protection: IP66
Dimensions: 800 x 45 x 36mm
Weight: 1.5kg
Operating Temperature: -40°C / +45°C
Cooling system: Convection
Input current: 600mA constant current (also possible at 350mA)
Controll system: Powered by Indalo Drive, Stand-alone or DMX
DMX-channels: 3
ncluded IP65 3-way serial connector
Attention: This high power LED fixture can not be installed under water
1.5
Outdoor 66
Dimensions in mm
IP20 RJ45
connector
cable length: +/- 1.9mtr
66
OUTDOOR RATED
L
IGHTING
Architainment
Height Indalo Strip-18RGB 30.4°
1m
2m
4m
6m
8m
10m
LED
technology
Red Green Blue
Diam.
532 Lx 650 Lx 142 Lx
0.54m
950 Lx 1160 Lx 253 Lx
133 Lx 163 Lx 35 Lx
1.08m
238 Lx 290 Lx 63 Lx
33 Lx 40 Lx 9 Lx
2.17m
59 Lx 72 Lx 16 Lx
15 Lx 18 Lx 3.9 Lx
3.26m
6.9 Lx
26 Lx 32 Lx
7.9 Lx 10 Lx 2.1 Lx
4.34m 15 Lx 18 Lx 3.9 Lx
5.3 Lx 6.5 Lx 1.4 Lx
5.41m 9.3 Lx
11 Lx 2.5 Lx
Eavg Eavg Eavg
Emax Emax Emax
R+G+B
1208 Lx
2156 Lx
302 Lx
539 Lx
75 Lx
134 Lx
33 Lx
59 Lx
18 Lx
33 Lx
12 Lx
21 Lx
Eavg
Emax
