Electromagnetic Flowmeter COPA-XT
8.
Circuit Boards
Top View
Side View
Abb. 28
Converter Insert COPA-XT
Abb. 29
Display Plate and ext. EEPROM Socket Location
24
Ext. EEPROM Socket
Display
Fuse Si F201
Minifuse Si F201
F201
Ext. EEPROM Socket
9803N1031/A1
→ V 49.9800 l/s
→ V 1349.00 m3
Display
A
Bailey-Fischer& Porter
Replacement Part No.
0.125
D151F003U14
Magnetic Stick Operation
