ABB COPA-XT DT43F Instruction Bulletin page 26

Electromagnetic Flowmeter COPA-XT
Submenu/Parameter
Submenu
Totalizer
Submenu
Display
20
Entry Type
Function Test
RAM (internal)
from table/numeric
Totalizer → F
ENTER reset
Totalizer → F
4697.00 m3
Overflow → F
250
Totalizer ← R
reset
Totalizer ← R
625.000 m3
Overflow ← R
004
Tot. Function
Standard
from table
1 Line
ENTER Q [%]
2 Line
Totalizer
1 Line Multipl.
Q [Bargraph]
2 Line Multipl.
off
Comments
Function test of the int. subassemblies, auto. tests, RAM (inter-
nal), EPROM (Progr.), lower EEPROM, upper EEPROM,
Ext. EEPROM, Terminals V8/V9, Pulse Output (1 Hz), Display
HART-Transmitter, HART-Command, Simulation and Test Mode.
Exit from submenu
C/CE
The overflow counter can be reset with ENTER key.
If the overflow counter > 0, then the message Overflow >F reset is
displayed.
Preset the totalizer (any totalizer value can be entered)
2nd line = present value
Overflow counter max. 250, 1 overflow = pulse totalizer
>9,999,999 units (displayed totalizer value is reset and one
overflow is registered).
See forward direction totalizer
See forward direction totalizer
See forward direction overflow counter
Standard = separate forward and reverse flow totals
each on its own totalizer.
Diff. totalizer = Forward and reverse flow totals are registered
on a single totalizer and the difference
displayed.
Exit from submenu
C/CE
Selections for the 1st line of the display: Flowrate in %, eng'g
units, mA, bargraph, totalizer, forward totalizer, reverse totalizer,
TAG-Number or blank line.
See 1st Line
In the multiplex mode it is possible to display an additional value
in the 1st line:
Flowrate in %, Eng'g units, mA, bargraph, totalizer, forward total-
izer, reverse totalizer, TAG-Number or blank line.
Display alternates every 10 seconds,
See 1st line multiplex
