Explanatory diagram of the overall ebike configuration
Passenger
seat
Tail light
Rear fender
Rear disc
brake
Mechanical
Electric motor
gears shifter
Actual product may slightly differ from this picture
Seat
Seat post
Seat post quick release
lever
Folding hinge
Transmission chain
Motor quick connector
Handlebar
angle
andjadjustment
mechanism
Battery
Folding
release lever/
lock
Pedal
QQuick connectors
Front cargo
basket. 30Lbs.
payload
Front lights
Front fender
Front
suspension
Front disc brake
Front brake caliper
3
3
