Error codes

In the event of a system malfunction the screen will display an error code. You can troubleshoot the problem by identifying
the code from the following chart.
End user adjustable settings
The display allows for a series of adjustments on the settings, however some are reserved exclusively for the use of a certified
technician of the manufacturer. For those others within reach of the end user please follow the below list of settings.
To enter the program mode, press and hold the UP and DOWN arrows for a few seconds. Use the M button to navigate navigate
through the settings and up and down t change settings in each program. The settings will automatically save if you leave the display
to go back to the home screen:
P01: Back-light Brightness (1: darkest; 3: brightest)
P02: Mileage Unit (0: KM; 1: MILE)
P04: Display sleep time (0: never, other figures refer to the sleep time) Unit: minute
P08: Speed Limit
Range: 0-100km/h, parameter 100 indicates no speed limit.
This parameter limits the max. speed of the vehicle.
For example, input value 25 means the max. speed is 25km/h, the vehicle traveling speed can only reach the preset value. Deviation:
±1km/h (applies to both PAS and throttle mode).
Note: The above-mentioned values are measured by metric unit (kilometers). When the measuring unit is switched to imperial unit
(mile), the speed value displayed on the panel will be automatically switched to corresponding imperial unit, however the speed limit
value in the imperial unit interface won't change accordingly.
P16: ODO Zero-Out: Long press the upper key for 5 seconds and ODO will zero out.
Error Code
0
1
2
3
4
5
6
7
8
9
10
11
12
13
Definition
Normal system, no error
Reserved, no function
Brake sensor error
PAS sensor failure
6 km/h capped top speed
Real time cruising
Low battery
Electric motor failure
Throttle failure
Controller failure
Communication-receiving error
Communication-sending error
BMS communication error
LED light failure
