- Page 1 Assembly instruc/ons...
- Page 2 Your EMOJO Panther Pro comes packed in 1 box, it is advisable to handle the box in a team of2 people due to the weight and size. 1-Inspect the box for any severe damage during shipping. PACKAGE It is recommended to use a clean, padded surface to work on to avoid scratches and possible damage to some of the parts when assembling; you can unfold the carton box and use it as working area.
- Page 3 1- Iden/fy all the parts included: A) Main frame (with preassembled front suspension, crank and handlebar) B) Seat with pole C) 2 Wheels D) Box containing baTery E) Box containing charger F) Rear rack G) Front fender with moun/ng hardware H) General hardware for assembly I) Front and rear LED lights PARTS...
- Page 4 2-Remove all zip /es holding the parts to the frame, be careful not to cut, scratch or puncture any of the components when cuXng the zip /es. 3-Remove and discard all protec/ve padding from the components. Remove aTached parts CAUTION: Be extremely careful when cuXng the zip /es to avoid puncturing /res, scratching the frame , or damage any parts.
- Page 5 4- Remove the baTery and keys from the box and set aside for further use. Remove aTached Parts B...
- Page 6 5-Keeping cables, wires and the brake handles forward, slide the neck down over the top of the fork where the plas/c cap was removed. the handlebar is already preassembled with the hand controls and LCD screen. A) Remove the protec/ve cap B) Insert the handlebar (A) Remove cap (B) Insert the handlebar HANDLEBAR Con/nues next page…...
- Page 7 6- Tilt the neck and handlebar assembly down and forward by sliding the lock tab and then li[ing up the tension lever. HANDLEBAR Con/nues next page…...
- Page 8 7-Secure the neck to the frame by /ghtening the bolt inside the neck, /ghten very firm but do not over –torque the bolt. 8-Bring the handlebar up and back to your desired angle, use the tension bolt (a) to firm up the the locking level and bring down the locking lever (b) to hold the handlebar in posi/on. HANDLEBAR (a) Tighten tension bolt (b) Close locking lever Secure the neck Con/nues next page…...
- Page 9 9-Align the handlebar so is aligned with the frame, use the screws on the side of the neck to /ghten it in place. HANDLEBAR...
- Page 10 It is highly recommended you install the front fender before the front wheel to allow you more room to secure the fender nuts and bolts to the fork. 10-ATach the curved support bracket to the front fender 11- Using the threaded eye holes on the front forks, aTach both plas/c bar clamps to each side using the screws provided. 12- ATach the top bracket of the fender and the headlamp to the forks, using the long bolt provided. Once the long bolt is thru the hole at the top of the forks, secure it with the nut on the back. FRONT FENDER AND HEADLAMP Secure long bolt with the safety nut on the back (10) (11) (12) Con/nues next page…...
- Page 11 13-Insert both sides of the moun/ng bar to the each bar clamp. 14- Line up fender and headlamp, /ghten the nut at the top and the set-screws in the plas/c bar clamp. FRONT FENDER AND HEADLAMP Headlamp wiring con/nues next page…...
- Page 12 15-Connect the wires from the bike to the lamp, the wire with the text on it is the + (posi/ve), the wire with no text is the – (nega/ve) 3-To turn on the headlight, first turn on your display by pressing the M buTon, then press and hold the UP arrow for a few seconds. HEADLAMP Posi/ve wire Posi/ve wire input on the headlamp rear.
- Page 13 To turn your headlight on: 1-Turn on your electric system by pressing and holding the M buTon for 3 seconds 2-Press and hold the arrow Up buTon un/l the light comes on, you will see the light icon on the screen 3-To turn off the light press and hold the Up buTon again. The light icon will turn off from the screen. HEADLAMP Press and hold UP buTon to turn light on/off 1-Press and hold M buTon to turn system on...
- Page 14 16-Remove the support bar (A) from the end of the forks, it is intended for shipping only, it can be discarded. 17-Remove the retaining clip (B) from the front brake caliper and discard 18-Slide the disc brake between the the brake pads into the caliper as you place the wheel into the fork. 19-Remove the end nut and spring from the front quick release axle (C) (B) FRONT WHEEL (C) (A) Con/nues…...
- Page 15 20-Run the axle rod thru the hole on the wheel hub, the tension lever should be on the opposite side of the brake caliper. 17-Slide the spring on and aTach the end nut, depress the lever to lock the wheel in place. 18-Tighten and adjust the front brake: Spin the front wheel and make sure it rolls smoothly, if you no/ce it drags or rubs considerably with both or one side of the brake caliper then the caliper needs to be balanced and adjusted: Loosen the 2 allen socket head bolts facing towards the back of the bike. Gently move the caliper un/l it no longer rubs against the disc brake, and /ghten the bolts again. FRONT WHEEL Note: Before completely Gghtening the screws, balance the front brake disc between the brake pads on both sides of the caliper, this will prevent the disc from rubbing, allowing for a smoother and quieter ride.
- Page 16 19-The pedals are inside the accessory box, iden/fy the le[ and right pedals, they are clearly marked with the R and L leTers. Install each pedal on its corresponding crank side, hand /ght first, then use the wrench to fully /ghten. PEDALS...
- Page 17 20-ATach the rear light to the rack using nuts and flat washers on the back of the light housing. 21-Fix the rack to the bike rear end using the provided bolts, aTach one side first, top and boTom threaded holes but to not /ghten all the way yet. A[er you have one side started, aTach the screws to the opposite side of the rack and /ghten all 4 screws. REAR RACK AND LIGHT Con/nues…...
- Page 18 22-Run the tail light wiring thru the frame of the bike, secure it using zip /es and connect the socket to the tail light. REAR RACK AND LIGHT...
- Page 19 23-Place the baTery over the open slot in the frame with the connector facing down and towards the front of the bike. 24-Set the boTom end of the baTery down into the bike and lower the front of the baTery, push it down firmly to lock it in place. NOTE: The keys are only used to lock or release the baTery to remove it, they are NOT used to turn on the bike electrical system. Keep them in a safe place, do not store both keys together in the sample place. BATTERY Socket facing Set the boTom end forward...
- Page 20 25-If needed, aTach the clamp into the frame 26- Insert the seat, adjust it to the desired height and secure it by /ghtening the seat post clamp. SEAT...
- Page 21 Turning on the bike: (a) Charge your battery for 4.5 to 5 hours for the first time. (b) Press and hold the M button on the handlebar left side control for 5 seconds until it turns on. (d) Adjust the pedal assist level using the up/down arrow buttons FINAL SETTINGS Tire pressure...
