OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Caddy and is the answer not in the manual?

Questions and answers

Related Manuals for EMOJO Caddy

Summary of Contents for EMOJO Caddy

  • Page 1 OWNER’S MANUAL...
  • Page 2 LCD Control keys PAS Control 9- 1 2 Front wheel installation and seat adjustment Contact us...
  • Page 3 Instructions 1. Please read the manual carefully before using the electric bicycle. 2. Make sure all parts are locked tightly, such as the frame joint, driver hand pipe, seat post and pedal, etc. before using. Do not use electric bicycle before carefully reading the instructions and knowing about the performance of the electric bicycle. Do not lend the electric bicycle to anyone who does not know how to operate it.
  • Page 5 Overall Bike Layout Stem Quick wiring connectors Front basket. Max. Rear basket. capacity: 55 Lbs Max. Seat pole capacity: 55 Lbs Headlight Seat pole quick Battery (optional) release lever Pedals Rear disc brake Electric motor Actual product may slightly differ from this picture...
  • Page 6 Rear fenders Front fender Controller board box Front disc brake Actual product may slightly differ from this picture...
  • Page 7 Diagram of the Electric Bicycle:...

  • Page 8: Main Technical Parameters

    Main Technical Parameters Item Index Total Weight lbs. <55 Load weight (including the Weight of Cyclist) lbs. ::;250 Travel Mileage on a single Charge Miles w/pedal assist Winter::::25 Summer::::40 Power Consumption on a single Charge (kilowatt) <0.6 Power Consumption per Kilometer (kilowatt) <1.2 Type Lithium Ion Battery...

  • Page 9: Hand Throttle Control

    Hand Throttle Control Your EMOJO electric bike is equipped with a power and throttle control which can be fixed on wither the on the right or left hand side. To power on your bike first make sure the switch to your battery is in the ON position.
  • Page 10 LCD Control keys There are several functions on the screen of your Caddy trike, all of the functions and settings are controlled by the 3 keys on the left side handlebar module. 3-Key control module on the left side of the handlebar The key operations consists of short press, long press or a combination of 2 keys: Short press UP/DOWN keys: Change PAS assist level during riding.
  • Page 11 Correct Operation Stages ! Warning: For your safety, please practice in open tracts the first time you ride. After mastering the controls of an electric bicycle, you may ride on regular roads and follow the traffic rules consciously. Do not let inexperienced people ride the electric bicycle, do not disassemble and refit the electric bicycle, please pay attention and brake in advance to allow longer braking distance in rainy or snowy weather.
  • Page 12 Pedal Assist Mode Control LCD Please read the following steps and images to help you understand how to read and operate all the functions. ◆Display Interface After switching on the E-bike system, the display shows current speed and total distance except, battery indicator and assistance level ◆To change the indicated information, press the MODE button to show in turn as follows: Current Speed (Km/h) →...

  • Page 13: Display Functions

    Display functions Pedal Assist Mode LCD Screen 1-Power On/Off Press the M button to power on the display. To power off display and power The LCD shows: Speed, Motor Power Ratio Disp l ay, Battery Leve l , supply to the bicycle press and hold for 3 seconds Error Indication, Tota l Mi l eage, Sing l e trip mi l eage, Cruise Contro l , 3-Riding Mode Sing l e Running Time, Light on.
  • Page 14 Meaning Code Indications Front LED ligtht is ON 0x01 Normal condition 0x02 Brake problem(electromagnetism) Check brake lever 0x03 Brake problem(power off) Check brake lever 0x04 Throttle is not Initialization Check the throttle 0x05 Throttle is damaged Change the throttle 0x06 Battery low-voltage protection Check the battery voltage and capacity...
  • Page 15 Charging Methods and Steps 1. Always charge the battery fully for the first time. When the battery level is low plug it to charge it, use only the original charger provided with the battery. Slide open the protective hatch to access the charging port 2.
  • Page 16 Attention: I. Make sure the charger is the original charger. 2. All charging plugs must be inserted tightly. 3. The average charging time of the whole battery pack is 6-8 hours, pl ease operate in strict accordance with above instructions and keep charger away from children.
  • Page 17 Read the instructions carefully to identify and understand the components of the electric bicycle such as pedal, seat post etc. and the name of relevant spare parts. When specialized servicing of bike is required, please go to an authorized EMOJO repair shop or store or another trusted bike professional.

  • Page 18: Disc Brakes

    WARNING: • Disc brake rotors become hot during use. Do not touch Your EMOJO e-bike is equipped with disc brakes for maximum or come in contact with the disc rotor shortly after use. reliability. Applying hand pressure to the brake levers will engage the •...
  • Page 19 4. Pedal Installation and Adjustment: Take out pedals from the accessory box, install one of the pedals (pedals are marked with the letters "L" and "R" to indicate the side they belong to). When installing the pedals, insert the wrench stuck on the flat end of pedal axial head, and twist into the crank in clockwise direction. 5.
  • Page 20 7. Adjustment of Power Assisting Hall Sensor A: Turn the bike upside down, have it rest on the floor. I: The distance between the sensor and the disk shall be 3-5 millimeters :: Installing the sensor on the side of chain ring, when forwarding the chain ring, the power assistance is effective.
  • Page 21 Check the charger and power. Check whether the battery connection is in good condition and is stable. Check whether the charger plugs board fails. Check for any blown fuses in the battery case or any Battery Not Charging disconnected wiring. Note: if you experience problems contact your retailer, dealer or the manufacturer.
  • Page 22 Power Shut Off Troubleshooting If your EMOJO Lynx experiences a sudden power shut off while in use, this can be related to several reasons but the problem has an easy fix. PROBLEM DIAGNOSTIC The LED module on the handlebar starts to blink repeatedly 1- Check the battery directly, press he power button to followed by a power shut off.

  • Page 23: Electric Bike Faqs

    The range with throttle only lasts about 20 miles (35 km) headwinds on my EMOJO electric bike? A. Yes. One of the main advantages of cycling on an EMOJO electric bicycle is that it How do I know when the battery is low? literally flattens hills and increases your average speed when tackling inclines and A.
  • Page 24 At EMOJO we are commited to the consumers and the experience first, put a smile on the face of each of EMOJO rider and revive childhood memories when riding a bike meant freedom regardless of your age or gender, life doesn’t stop and neither should you, that’s why we say: “RIDE LIFE”...
