LOGICDATA COSMO Austin Owner's Manual page 13

STEP 1: PREPARING THE OUTER FRAME
DO NOT REMOVE PROTECTIVE MATERIAL
DO NOT REMOVE STRAPPING TAPE
L L
W A
A
USE LABELS ON SIDE RAILS
STEP 2: ATTACHING THE LEGS
C
Lay the Crossbars (D) and Side Rails (A,
B) on the ground, as shown in the picture.
IMPORTANT:
• Ensure the Crossbars are parallel
• Use the labels on the Side Rails to
• Use the Crossbars to determine
B
A B
ADJUSTABLE BED FRAME - OWNER'S MANUAL //
and roughly 5 feet (150 cm) apart.
ensure they are oriented correctly.
the position of the Side Rails. The
Side Rails should be the width of the
Crossbar apart.
D
1.
the Side Rail (A/B) as shown in
the picture.
2. Turn the Leg to screw it into
the Side Rail. It should be hand
tight.
3. Repeat Steps 1 and 2 to Screw
in the other 3 Legs.
(C) below
13
