Southern Enterprises MS9350 Manual

SOUTHERN ENTERPRISES INC.

RELAX...If you can follow a few easy, step-by-step directions

in order .YOU CAN ASSEMBLE THIS ITEM.

PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL.

(1) WOOD DOWEL

(2) CAM-BOLT

(3) CAM-LOCK

(4) COVER

(A) DRAWER LEFT SIDE PANEL

(B) DRAWER FRONT PANEL

HARDWARE LIST

12PCS

Ø6X25mm

8PCS

1PC

STYLE NO.

MEDIA STORAGE OTTOMAN

(5) METAL SUPPORT

(6) SHORT WOOD SCREW

(7) LONG WOOD SCREW

(G) RIGHT SIDE PANEL

(H) BACK PANEL

(I) SHELF

MS9350

Ø3x12mm

Ø3x19mm

1PC

10PCS

8PCS

1PC

Table of Contents

Do you have a question about the MS9350 and is the answer not in the manual?

Page 1 MS9350 STYLE NO. MEDIA STORAGE OTTOMAN SOUTHERN ENTERPRISES INC. RELAX...If you can follow a few easy, step-by-step directions in order .YOU CAN ASSEMBLE THIS ITEM. PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL. HARDWARE LIST (1) WOOD DOWEL...
Page 2 (J) FRONT PANEL (D) DRAWER BACK PANEL (E) DRAWER BOTTOM PANEL (K) CUSHION (F) LEFT SIDE PANEL ASSEMBLY INSTRUCTION SELECT A SMOOTH, SOFT SURFACE TO PREVENT SCRATCHING FINISH. YOU MAY NEED A PHILLIP SCREWDRIVER. INSERT LONG WOOD SCREWS (7) THROUGH PREDRILLED HOLES ON OUTSIDE OF DRAWER LEFT SIDE PANEL (A) AND TIGHTEN INTO CORRESPONDING HOLES ON ENDS OF DRAWER FRONT AND BACK PANELS (B, D).
Page 3 INSERT WOOD DOWELS (1), CAM-BOLTS (2) INTO PREDRILLED HOLES ON BACK OF FRONT PANEL (J) AND FIT INTO CORRESPONDING HOLES ON FRONT EDGES OF LEFT AND RIGHT SIDE PANELS (F, G). INSERT CAM-LOCKS (3) INTO BIG HOLES ON INSIDE OF LEFT AND RIGHT SIDE PANELS (F, G) WITH SLOT FOR SCREWDRIVER FACING OUTWARD.
Page 4 PARTS REPLACEMENT FORM STYLE NO MS9350 Customer Name PARTS PART QUANTITY LETTER DESCRIPTION NEEDED Street, City, State, Zip Phone# Please indicate where you purchased this item. Store/website/catalog Please indicate color/size/style number SOUTHERN ENTERPRISES INC. P.O. Box 59996 Dallas, Texas 75229...
