- Page 1 MS99320TX –Antonio Rustic Plank TV Console- Distressed Weathered Oak For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 ASSEMBLY INSTRUCTIONS service@seidal.com www.seidal.com PO#:...
-
Page 2: Parts List
Antonio Rustic Plank TV Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Quantity of 22 Quantity of 22 Quantity of 2 ∮6.8x36 mm ∮15x12 mm ∮2.5x12 mm Cam Bolt Cam Lock Screw Quantity of 2 Quantity of 2 Quantity of 2 Left Hinge Right Hinge Wood Dowel 8 x30 Quantity of 26 Quantity of 12 Quantity of 11 ∮3x12 mm...
- Page 4 Antonio Rustic Plank TV Console Assembly Instructions Figure 1 Attach left/right middle panels (D) and ( 1 ) ( 2 ) (E) to fixed shelf panel (F) using cam bolts (1) and cam locks (2) as shown. “Please do not over tighten cam bolts, stop when you feel them tighten"...
- Page 5 Figure 3 Attach left/right side panels (B) and (C) to bottom panel (G) and cross panel (H) using cam bolts (1) and cam locks (2) as shown. Attach center support leg (S) to the bottom panel (G). Figure 4 Attach wood top (A) to left/right side panels (B), (C), cross panel (H) and left/right middle panels (D) and (E) using cam bolts (1), cam locks (2),...
- Page 6 Figure 5 Attach back panel (R) to the back of frame by using screw (7) as shown To assemble the drawer, attach Figure 6 drawer left side panel (O) and drawer right side panel (P) to drawer front panel (N) using wood screws (9).
- Page 7 Figure 7 Attach left door (I) and right door (J) to the frame by using hinge (4) and (5) using screws (14) as shown. Insert the drawer making sure the glides slide smoothly. Figure 8 Insert shelf holders (8) and place on the shelves (K) and (L) as shown.
- Page 8 Now your Antonio rustic plank TV Figure 9 console is ready to use.
-
Page 9: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 10 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Model: MS993200TX Antonio Rustic Plank TV Console Southern Enterprises, Inc 600 Freeport Parkway, Suite 200 Coppell, Texas, 75019 Manufacture Date:04/15/2014...
