TK180 MET PRES UHF
1. Paper out
2. Display
3. Autocutter
4. Device cover
5. Device chassis
6. RFID reader
7. Adjustable cursor for
paper in
8. Paper input
9. ON/OFF key
10. Connector for low paper
sensor (external)
11. RS232 serial port (RJ45)
12. Ethernet port
13. USB port
14. Power supply port
15. Status LED
16. FF key
17. LF key
1
2
3
4
7
8
9
10
11
12
13
14
TK180 MET UHF
1. Paper out
2. Display
3. Device cover
4. Device chassis
5. RFID reader
6. Adjustable cursor for paper in
7. Paper input
8. ON/OFF key
9. Connector for low paper sensor
(external)
5
6
10. RS232 serial port (RJ45)
11. Ethernet port
12. USB port
13. Power supply port
14. Status LED
15. FF key
16. LF key
15
16
17
1
2
3
4
6
7
8
9
10
11
12
13
5
14
15
16
