- Page 1 VG24300 ASSEMBLY INSTRUCTIONS JIMINY PICKET ASSEMBLY INSTRUCTIONS VINYL GATE VG24300 (4’H X 4’W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 042921...
- Page 2 VG24300 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 VG24300 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
- Page 4 VG24300 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS 48in. 48in. 50.5 36in. 24” 2in. 3in. Ground 50in. 36” 54.5in. WamBam Anchor (Small) (Large) .090in. wall thicknes 1.5in. 2.89in. 3in. 3.5in. 3.5in. 1.5in. 4in. 3.5in. 47.5in. 24.75in. 3.5in. 1.5in. 7.75in. 3.5in.
- Page 5 VG24300 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Latch Catch (1) Corner Bracket (2) T-Bracket (2) Post Cap (2) Latch Finger (1) 11/4” White Self- Drilling Stainless Steel Screw (20) Metal Post Stabilizer (1) Picket Cap (7) Gate Jig (1) 1½”...
- Page 6 VG24300 ASSEMBLY INSTRUCTIONS INSTALL GATE JIG, POST ANCHORS, AND POSTS STEP 2: STEP 2.1 STEP 2.2 Identify the location of your gate. Dig a trench Identify the location of the Metal Post 60” long x 6” wide x 5½” deep. Stabilizer and pound it into the ground.
- Page 7 VG24300 ASSEMBLY INSTRUCTIONS STEP 2.7 Make sure to fasten the fence panels before attaching the gate. ASSEMBLE THE GATE FRAME BOTTOM AND SIDES STEP 3: STEP 3.1 until it bottoms out inside Corner Bracket (A). Insert the Bottom Rail Note: The bottom rail is ribbed internally.
- Page 8 VG24300 ASSEMBLY INSTRUCTIONS ASSEMBLE THE GATE FRAME TOP STEP 4: STEP 4.1 Insert the Top Rail all the way until it bottoms out inside the T-Bracket (B). FINISH ASSEMBLING THE GATE FRAME STEP 5: STEP 5.1 Slide the gate frame top down over the vertical stiles.
- Page 9 VG24300 ASSEMBLY INSTRUCTIONS STEP 5.2 Screw the brackets with (16) 11/4” white self-drilling stainless steel screws as illustrated. The corner-to-corner measurements must be the same to ensure the gate is square and the width of the gate should be 48”. Note: The gate hinges will be installed under the screws on...
- Page 10 VG24300 ASSEMBLY INSTRUCTIONS INSERT PICKETS AND ATTACH PICKET AND STEP 6: POST CAPS STEP 6.1 STEP 6.2 Insert the Pickets (K), with the tabs at the Use the Vinyl Glue bottom through the top rail and into the to glue the Picket Caps bottom rail.
- Page 11 VG24300 ASSEMBLY INSTRUCTIONS FASTEN HINGES AND GATE LATCH STEP 7: STEP 7.1 Fasten the Latch Finger to the gate brackets with (6) 11/4” Black Self-Drilling Stainless Steel Screws (P). Fasten the Hinges onto the opposite side of the gate with (12) 11/4” black self-drilling stainless steel screws.
- Page 12 VG24300 ASSEMBLY INSTRUCTIONS ASSEMBLE AND FASTEN GATE BRACE STEP 8: STEP 8.1 Assemble the Gate Brace by sliding the larger square tube over the smaller square tube. Align the holes and install by using the included hardware. STEP 8.2 Double check that the gate is square and then screw the gate brace into place with (4) 1/2”...
- Page 13 VG24300 ASSEMBLY INSTRUCTIONS ALIGN GATE AND SECURE HINGES TO POST STEP 9: STEP 9.1 Align the gate to the horizontal fence rails. Note: Both the fence & gate hori- zontal rail spacing can be adjusted to lower heights. STEP 9.2A Fasten the hinges to the posts as illustrated.
- Page 14 VG24300 ASSEMBLY INSTRUCTIONS STEP 9.2B How to position the screws on the post side of the hinge: Using a ⅛” drill bit, pre-drill the holes for the hinge screws as illustrated. Angle your drill slightly as illustrated. Note: Swing the gate open and pre-drill four more holes for the hinge screws as illustrated.
- Page 15 VG24300 ASSEMBLY INSTRUCTIONS LEVEL GATE AND ADJUST HINGES STEP 10: STEP 10.1 STEP 10.2 Using a level, make sure that the The hinges can be adjusted moderately to bring gate fits and functions with its the gate into level alignment with the post. latching post.
- Page 16 VG24300 ASSEMBLY INSTRUCTIONS INSTALL LATCH CATCH STEP 11: STEP 11.1 Align and fasten the Latch Catch with (6) total 11/4” black self-drilling stainless steel screws. The latch catch should be set so that it is aligned with the height of the latch finger.
- Page 17 VG24300 ASSEMBLY INSTRUCTIONS INSTALL OVER A ALTERNATIVE APPLICATION: SIDEWALK OR PATH STEP 1.1 Option 1: If the sidewalk is less than 52”, use the gate jig as a temporary spacer. Proceed installing the panels according to the fence’s install guide. Sidewalk/path INSTALL OVER A ALTERNATIVE APPLICATION:...
- Page 18 VG24300 ASSEMBLY INSTRUCTIONS YOUR GATE DESIGN: CUSTOMIZE Use the cutting guide below to trim your pickets to create a custom gate design. This gate can also be trimmed down both in width and height to accommodate custom applications. Cut down the vertical stiles by 6”...
