- Page 1 VG26200 ASSEMBLY INSTRUCTIONS PEEPING TOM ASSEMBLY INSTRUCTIONS VINYL GATE VG26200 (6’H X 4’W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 062221...
- Page 2 VG26200 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 VG26200 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
- Page 4 VG26200 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS 4.5in. 1.1in. 48in. 3.5in. 4.0in. 73.5in. 72in. 71.62in. 48.88in. 36in. 2in. 3in. Ground 7.75in. 3.5in. 50in. 48in. 54.5in. 44in. 1.5in. 1.5in. WamBam Anchor 3.5in. (Large) 1.5in. 3.5in. 3.5in. 1.5in. 3.5in. .090in. wall thickness...
- Page 5 VG26200 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Hinge (2) Corner Bracket (2) T-Bracket (2) Post Cap (2) Latch Catch (1) Latch Finger (1) 1¼” White Self-Drilling Metal Post Stabilizer (1) Picket Cap (7) Gate Jig (1) Stainless Steel Screw (24) 1½”...
- Page 6 VG26200 ASSEMBLY INSTRUCTIONS INSTALL GATE JIG, POST ANCHORS, AND POSTS STEP 2: STEP 2.1 STEP 2.2 Identify the location of your gate. Dig a trench Identify the location of the Metal Post 60” long x 6” wide x 5½” deep.
- Page 7 VG26200 ASSEMBLY INSTRUCTIONS STEP 2.7 Make sure to fasten the fence panels before attaching the gate. ASSEMBLE THE GATE FRAME BOTTOM AND SIDES STEP 3: STEP 3.1 until it bottoms out inside Corner Bracket (A). Insert the Bottom Rail Note: The bottom rail is ribbed internally.
- Page 8 VG26200 ASSEMBLY INSTRUCTIONS ASSEMBLE THE GATE FRAME TOP STEP 4: STEP 4.1 Insert the Top Rail all the way until it bottoms out inside the T-Bracket (B). FINISH ASSEMBLING THE GATE FRAME STEP 5: STEP 5.1 Slide the gate frame top down over the vertical stiles.
- Page 9 VG26200 ASSEMBLY INSTRUCTIONS STEP 5.2 Fasten the brackets with (20) 11/4” White Stainless Steel Screws as illustrated. The corner-to-corner measurements must be the same to ensure the gate is square and the width of the gate should be 48”. WWW.WAMBAMFENCE.COM...
- Page 10 VG26200 ASSEMBLY INSTRUCTIONS INSTALL PICKETS AND ATTACH PICKET AND STEP 6: POST CAPS STEP 6.1 STEP 6.2 Insert the Pickets (H), tab end first, through Use the Vinyl Glue the top rail and into the bottom rail. to glue the Picket Caps and attach them to the top of the pickets.
- Page 11 VG26200 ASSEMBLY INSTRUCTIONS FASTEN HINGES AND GATE LATCH STEP 7: STEP 7.1 Fasten the Hinges and the Latch Finger onto the gate brackets with (18) total 1¼” Black Self-Drilling Stainless Steel Screws as illustrated. WWW.WAMBAMFENCE.COM...
- Page 12 VG26200 ASSEMBLY INSTRUCTIONS ASSEMBLE AND FASTEN GATE BRACE STEP 8: STEP 8.1 Assemble the Gate Brace by sliding the larger square tube over the smaller square tube. Align the holes and install by using the included hardware. STEP 8.2 Double check that the gate is square and then screw the gate brace into place with (4) 1/2”...
- Page 13 VG26200 ASSEMBLY INSTRUCTIONS ALIGN GATE AND SECURE HINGES TO POST STEP 9: STEP 9.1 Align the gate to the horizontal fence rails. Note: Both the fence & gate horizon- tal rail spacing can be adjusted freely to lower heights. STEP 9.2A Fasten the hinges to the posts as illus- trated using (6) total 2”...
- Page 14 VG26200 ASSEMBLY INSTRUCTIONS STEP 9.2B How to position the screws on the post side of the hinge: Using a ⅛” drill bit, pre-drill the holes for the hinge screws as illustrated. Angle your drill slightly as illustrated. Note: Swing the gate open and pre-drill four more holes for the hinge screws as illustrated.
- Page 15 VG26200 ASSEMBLY INSTRUCTIONS LEVEL GATE AND ADJUST HINGES STEP 10: STEP 10.1 STEP 10.2 Using a level, make sure the gate fits The hinges can be adjusted moderately to bring and functions with the latching post. the gate into level alignment with the post.
- Page 16 VG26200 ASSEMBLY INSTRUCTIONS INSTALL LATCH CATCH STEP 11: STEP 11.1 Align and fasten the Latch Catch with (6) total 11/4” black self-drilling stainless steel screws. The latch catch should be set so that it is aligned with the height of the latch finger.
- Page 17 VG26200 ASSEMBLY INSTRUCTIONS INSTALL OVER A ALTERNATIVE APPLICATION: SIDEWALK OR PATH STEP 1.1 Option 1: If the sidewalk is less than 52”, use the gate jig as a temporary spacer. Proceed installing the panels according to the fence’s install guide.
- Page 18 VG26200 ASSEMBLY INSTRUCTIONS YOUR GATE DESIGN: CUSTOMIZE Use the cutting guide below to trim pickets to create a custom fence design. This gate can also be trimmed down both in width and height to accommodate custom applications. 61¼ ” 64¼...
- Page 19 VG26200 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
