ASSEMBLY INSTRUCTIONS
EVEN STEVEN
VINYL GATE
(4'H X 4'W)
Approximate assembly time
Want to see a video on how to
assemble this product?
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
60 MIN
Scan the QR code
ASSEMBLY
INSTRUCTIONS
VG24100
VG24100
1
VER. 030121

Advertisement

loading
Need help?

Need help?

Do you have a question about the VG24100 and is the answer not in the manual?

Questions and answers

Summary of Contents for WamBam VG24100

  • Page 1 VG24100 ASSEMBLY INSTRUCTIONS EVEN STEVEN ASSEMBLY INSTRUCTIONS VINYL GATE VG24100 (4’H X 4’W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 030121...
  • Page 2 VG24100 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
  • Page 3 VG24100 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
  • Page 4 VG24100 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS Gate Assembly 1.5” 4.5” .090” wall thickness 4.5” 29.75” 12.25” 0.625” 8.75” 4.5” 30.5” 4.5” 48” .060” wall thickness Gate Installation 50.5” 48” 37” 24” 18.25” 50” 36” 44” 54.5” WamBam Anchor (Small) WWW.WAMBAMFENCE.COM...
  • Page 5 VG24100 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Latch Catch (1) Corner Bracket (4) Vertical Stile (2) Metal Post 1½” x 4½” x 29½” Stabilizer (1) Latch Finger (1) 11/4” White Self-Drilling Stainless Steel Screw (32) 11/4” Black Self-Drilling Horizontal Rail (2)
  • Page 6 VG24100 ASSEMBLY INSTRUCTIONS INSTALL GATE JIG, POST ANCHORS, AND POSTS STEP 2: STEP 2.1 STEP 2.2 Identify the location of your gate. Dig a trench Identify the location of the Metal Post 60” long x 6” wide x 5½” deep.
  • Page 7 VG24100 ASSEMBLY INSTRUCTIONS STEP 2.7 Make sure to fasten the fence panels before attaching the gate. ASSEMBLE THE GATE FRAME STEP 3: STEP 3.1 Insert (1) Vertical Stile until it bottoms out inside of (1) Corner Bracket (A). Note: The vertical...
  • Page 8 VG24100 ASSEMBLY INSTRUCTIONS SECURE GATE FRAME AND CORNER BRACKETS STEP 4: STEP 4.1 Screw the corner brackets with (32) 11/4” White Self-Drilling Stainless Steel Screws as illustrated. The corner-to-corner measurements must be the same to ensure the gate is square, and the width of the gate should be 48”.
  • Page 9 VG24100 ASSEMBLY INSTRUCTIONS FASTEN HINGES AND GATE LATCH STEP 5: STEP 5.1 Fasten the Hinges and the Latch Finger onto the gate brackets as illustrated using (18) 11/4” Black Self-Drilling Stainless Steel Screws (L). WWW.WAMBAMFENCE.COM...
  • Page 10 VG24100 ASSEMBLY INSTRUCTIONS ASSEMBLE AND FASTEN GATE BRACE STEP 6: STEP 6.1 Assemble the Gate Brace by sliding the larger square tube over the smaller square tube. Align the holes and install using the hardware (2 hex bolts, 2 lock washers, and 2 nuts) included with the gate brace.
  • Page 11 VG24100 ASSEMBLY INSTRUCTIONS ALIGN GATE AND SECURE HINGES TO POST STEP 7: STEP 7.1 Align the gate with the horizontal fence rails. Note: Both the fence and the gate horizontal rail spacing can be adjusted freely to lower heights. STEP 7.2A...
  • Page 12 VG24100 ASSEMBLY INSTRUCTIONS STEP 7.2B How to position the screws on the post side of the hinge: Using a ⅛” drill bit, pre-drill the holes for the hinge screws as illustrated. Angle your drill slightly as illustrated. Note: Swing the gate open and pre-drill four more holes for the hinge screws as illustrated.
  • Page 13 VG24100 ASSEMBLY INSTRUCTIONS LEVEL GATE AND ADJUST HINGES STEP 8: STEP 8.1 STEP 8.2 Using a level, make sure the The hinges can be adjusted moderately to gate fits and functions with the bring the gate into level alignment with the latching post.
  • Page 14 VG24100 ASSEMBLY INSTRUCTIONS INSTALL LATCH CATCH STEP 9: STEP 9.1 Align and fasten the Latch Catch with (6) 11/4” black self-drilling stainless steel screws to fit and function with the gate finger. Note: The latch is designed for left and right hand applications.
  • Page 15 VG24100 ASSEMBLY INSTRUCTIONS INSTALL OVER A ALTERNATIVE APPLICATION: SIDEWALK OR PATH STEP 1.1 Option 1: If the sidewalk is less than 52”, use the gate jig as a temporary spacer. Proceed installing the panels according to the fence’s install guide.
  • Page 16 VG24100 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
