ASSEMBLY INSTRUCTIONS
PREMIUM
VINYL ARCHED
(6' H X 4' W)
Approximate assembly time
Want to see a video on how to
assemble this product?
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
TOP GATE
60 MIN
Scan the QR code
ASSEMBLY
INSTRUCTIONS
VF13007
VF13007
1
VER. 022621
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WamBam VF13007
Summary of Contents for WamBam VF13007
- Page 1 VF13007 ASSEMBLY INSTRUCTIONS PREMIUM ASSEMBLY INSTRUCTIONS VINYL ARCHED VF13007 TOP GATE (6’ H X 4’ W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 022621...
- Page 2 VF13007 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 VF13007 ASSEMBLY INSTRUCTIONS AVOID THESE PITFALLS! HAVE YOU CONTACTED You must call your local utilities before you start installing YOUR LOCAL UTILITIES? your fence to avoid puncturing any unseen underground utilities, especially electrical or gas lines. Fortunately, this is made easy for you.
- Page 4 VF13007 ASSEMBLY INSTRUCTIONS TOOLS AND MATERIALS YOU’LL NEED Safety Glasses 1ft. Torpedo Level 4ft. Level (optional String Line Level) 2in. x 2in. x 6in. Inch Wood “Spacer” Block (2 for each panel) Cordless Drill (preferably with a high-torque setting) Shovel or Auger...
- Page 5 VF13007 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
- Page 6 VF13007 ASSEMBLY INSTRUCTIONS 48in. 3.5in. 11.75in. 73.5in. 70in. 50.45in. 62.7in. 72in. 94in. 2in. 7.8in. 3.8in. Ground 2in. 50in. 7.8in. 32.4in. 7. 8 in. 54.5in. 48in. 36in. 1.5in. 1.5in. 3.5in. 1.5in. 10in. Posts Sold Separately 3.5in. 1.5in. 3.5in. 3.5in. .090in. wall thickness...
- Page 7 VF13007 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: 1¼” Self-Drilling Stainless Steel Screw (20) Gate Arch (1) Gate Arch Top 1½” x 9” x 42¼” Bracket (2) 1½” x 3½” x 58¼” 1¼” Black Self- Drilling Stainless Steel Screw (24)
- Page 8 VF13007 ASSEMBLY INSTRUCTIONS ASSEMBLE GATE FRAME BOTTOM AND SIDES STEP 2: STEP 2.1 Use the Tube of Glue to run a bead of vinyl weld glue around the inside of the Corner Bracket (F). Note: Vinyl weld glue takes approximately five minutes to dry.
- Page 9 VF13007 ASSEMBLY INSTRUCTIONS INSERT PRIVACY BOARDS STEP 3: STEP 3.1 STEP 3.2 Insert the tongue and groove of Privacy Board Install Privacy tightly into the vertical stile as illustrated. Boards 2 (H), 3 (I), Continue to slide the privacy board until it bot- and 4 as illustrated.
- Page 10 VF13007 ASSEMBLY INSTRUCTIONS FASTEN BRACKETS STEP 5: STEP 5.1 Ensure your gate is square, and se- cure the gate brackets using (12) 11/4” Self-Drilling Stainless Steel Screws (N). ATTACH GATE HINGES AND LATCH FINGER STEP 6: OPTIONAL STEP 6.1 Insert the 23/4” Tension Pin into one of the holes in the spring chamber of the hinge.
- Page 11 VF13007 ASSEMBLY INSTRUCTIONS STEP 6.2 Fasten the Gate Hinges onto the gate brackets with (12) 11/4” Black Self-Drilling Stainless Steel Screws (O). STEP 6.3 Fasten the Latch Finger onto the gate arch top bracket with the (6) 11/4” black self-drilling stainless steel screws.
- Page 12 VF13007 ASSEMBLY INSTRUCTIONS ASSEMBLE AND FASTEN GATE BRACE STEP 7: STEP 7.1 Assemble the Gate Brace by sliding the larger square tube over the smaller square tube. Align holes and install by using the included hardware. STEP 7.2 Double check that the gate is square and screw the gate brace into place by using (4) 11/4”...
- Page 13 VF13007 ASSEMBLY INSTRUCTIONS ALIGN GATE AND SECURE HINGES TO POSTS STEP 8: STEP 8.1 Use wooden blocks as temporary spacers to rest the gate on during alignment and installation. STEP 8.2 Fasten gate hinges to the posts with (6) 2” Black Self-Drilling Stainless Steel Screws (P).
- Page 14 VF13007 ASSEMBLY INSTRUCTIONS LEVEL GATE AND ADJUST HINGES STEP 9: STEP 9.1 Fasten the hinges to the inside of the post with (8) total 2” black self-drilling stainless steel screws. Fasten the hinges to the inside of the gate brackets with (4) total 11/4” black stainless steel screws.
- Page 15 VF13007 ASSEMBLY INSTRUCTIONS INSTALL GATE LATCH STEP 10: STEP 10.1 Align and fasten the Latch Catch with (6) 11/4” black self-drilling stainless steel screws to fit and function with the gate finger. The latch is designed for left and right hand applications. Temporarily remove the spring and bolt and reverse the paddle portion as necessary.
