MVI56E-61850C ♦ IEC 61850 Client Communication Module
ControlLogix® Platform
2.2

Ethernet Ports

Port
Ports
Ethernet Port 1
Ethernet Port 2
2.3

IEC 61850 Specifications

Specification
Supported Standard
Maximum Number of IEDs
Supported Reports
Control
Maximum Number of Reports per IED
GOOSE
Maximum Number of GOOSE
Subscription per IED
Maximum Number of GOOSE Publish
Maximum Number of Tags per IED
Maximum Number of Tags
Status
2.4

Backplane Specifications

Specification
Maximum Number of Class 1
Connections
Maximum Number of Class 1 High
Priority Connections
High Priority Connection RPI Range
Normal Priority Connection RPI Range
Maximum Class 1 Connection Input
Size
Maximum Class 1 Connection Output
Size
ProSoft Technology, Inc.
Description
2 GbE
Application port
Redundant port (if redudancy is enabled)
Value
IEC 61850 Ed 2.0
40
Buffered Report Control Block (BRCB)
Unbuffered Report Control Block (URCB)
Direct-with-Normal-Security
SBO-with-Normal-Security
Direct-with-Enhanced-Security
SBO-with-Enhanced-Security
10
GOOSE Subscription
GOOSE Publish
4
8
500
20,000
Status available per node
Report and GOOSE status available
High-level status data available within Studio 5000
Value
225
50
[4..9,999] ms
[100..9,999] ms
500 bytes
496 bytes
Module Overview
User Manual
Page 11 of 116
