INSTRUCTION MANUAL
PY-700
7A10630400A1
Preface
Thank you for your purchase of the Medical Trolley (hereinafter called the "Trolley").
This Instruction Manual describes precautions and the assembly method for safe use of the trolley.
●
To ensure safe and proper use of the trolley, be sure to read this Instruction Manual before use.
●
After reading this instruction manual, store it in a place that can be easily accessed for later
reference.
●
Some of the descriptions in this instruction manual may differ from the product you have purchased due
to model refinements.
●
Values described for operation range, dimensions, angle, or mass may include some errors.
●
Excluding special cases, in this Instruction Manual for display purposes words such as approximately,
about, etc. are omitted.
●
Contact your dealer or Paramount Bed dealer for any queries.
Series
PY-702E
PARAMOUNT BED CO., LTD.
Medical Trolley
PY-713CD
Advertisement
Table of Contents
Related Manuals for PARAMOUNT BED PY-700 Series
Summary of Contents for PARAMOUNT BED PY-700 Series
- Page 1 Values described for operation range, dimensions, angle, or mass may include some errors. ● Excluding special cases, in this Instruction Manual for display purposes words such as approximately, about, etc. are omitted. ● Contact your dealer or Paramount Bed dealer for any queries. PARAMOUNT BED CO., LTD.
-
Page 2: Table Of Contents
INDEX INTENDED USE / PART NAMES ··················································· 2 SAFETY PRECAUTIONS ····························································· 3 – 4 CHECKING THE PARTS······························································ 5 – 7 ASSEMBLY PROCEDURE ··························································· 8 – 9 CASTERS ················································································· 9 SPECIFICATIONS ····································································· 10 REGULAR INSPECTION AND DAILY MAINTENANCE ······················ 11 LONG-TERM STORAGE······························································ 12 AFTER-SALES SERVICE ····························································... -
Page 3: Intended Use / Part Names
INTENDED USE / PART NAMES INTENDED USE This Medical Trolley is created for the purpose of carrying medical devices or for use as a work table in medical facilities, etc. PART NAMES * This illustration uses PY-703CD model for explanation. Product ID label (Affixed on the surface of the upper tray) -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Indicates that improper handling by ignoring this indication could cause death or WARNING serious injury (broken bones, pressure, or paralysis). ▪ Do not use the trolley for purposes other than those for which it is intended • Do not use for a purpose such as a handrail or walker. There is a risk of injury due to falling over, or the trolley could be damaged or deformed. - Page 5 Indicates that improper handling by ignoring this indication could cause death or WARNING serious injury (broken bones, pressure, or paralysis). ▪ Do not place hands on the trolley with the drawer pulled out • The trolley could fall over, resulting in injury, or it could be damaged or deformed. ▪...
-
Page 6: Checking The Parts
After unpacking the product, check that there are no missing or damaged parts. If any parts are missing or damaged, contact your dealer or Paramount Bed dealer. The number of parts depends on the type of the product; for details, refer to the Configuration Table. - Page 7 ▪ Configuration Table Medical Trolley Model PY-702D PY-702CD PY-703D PY-703CD Type ( D ) Drawer Type Treatment Type Treatment Type Treatment Type Series Upper Tray 1 tray 1 tray 1 tray 1 tray Middle Tray 1 tray 1 tray Bottom Tray 1 tray 1 tray 1 tray...
- Page 8 Medical Trolley Model PY-702E PY-702CE PY-703E PY-703CE Type ( E ) Drawer Type Treatment Type Treatment Type Treatment Type Series Upper Tray 1 tray 1 tray 1 tray 1 tray Middle Tray 1 tray 1 tray Bottom Tray 1 tray 1 tray 1 tray 1 tray...
-
Page 9: Assembly Procedure
ASSEMBLY PROCEDURE • Be careful when handling parts for assembling the trolley. There is a risk of WARNING injury due to falling parts or getting parts of the body caught in the parts. • After assembly, be sure to check that there is no rattling and that all screws are properly tightened. -
Page 10: Casters
PY-702D/E, PY-702CD/CE and, PY-712D/E (2-Stage type) Stand the wagon up and use the hexagonal ❺ wrench (6 mm) to firmly secure the cap bolts that were temporarily fixed in steps ❹ (8 locations) Hexagonal wrench PY-703D/E, PY-703CD/CE, PY-713D/E, (6 mm) PY-713CD/CE (3-Stage type) After standing up the wagon, align the position of ❺... -
Page 11: Specifications
SPECIFICATIONS Product name Medical Trolley ( D ) Series Model No. PY-702D PY-702CD PY-703D PY-703CD PY-712D PY-712CD PY-713D PY-713CD Length 54.8 Dimensions Width 61.4 61.4 79.4 91.3 79.4 91.3 (cm) Total 95.1 height Tray : 1 tray (cm) 46.5 (L) x 45.6 (W) x 3.8 (D) 46.5 (L) x 63.4 (W) x 3.8 (D) Drawer : 1 drawer(cm) 28.7 (W) x 44 (D) x 12.5 (H) -
Page 12: Regular Inspection And Daily Maintenance
Inspect for loose parts, the operation of casters, and the presence of damage regularly. ▪ If you notice an irregularity or want a detailed inspection, contact your dealer or Paramount Bed dealer. 2. DAILY MAINTENANCE ▪... -
Page 13: Long-Term Storage
Keep the instruction manual in a safe place so that they do not become lost. AFTER-SALES SERVICE Questions regarding after-sales service For any queries or when requesting repairs, contact your dealer or Paramount Bed dealer. ▪ Details necessary when requesting repair ●... - Page 14 '2019.05...
