Table Of Contents - THORLABS ERM100 Operation Manual

Contents
Foreword
1 General Information
1.1 Safety
1.2 Ordering Codes and Accessories
1.3 Requirements
1.3.1 Hardware Requirements
1.3.2 Software Requirements
2 Installation
2.1 Parts List
2.2 Getting Started
3 Operating Instruction
3.1 Operating Elements
3.2 Operation and Settings
3.2.1 Main Displays
3.2.2 Menu
3.2.2.1 Averaging
3.2.2.2 Remote State
3.2.2.3 Serial Number
3.2.2.4 Firmware Version
3.2.2.5 Bootloader Version
3.2.3 Remote Mode
3.2.4 Error Messages
3.3 Measurement Procedure
3.4 Measurement Principle
3.5 Coupling of linear polarized light into a main axis of a PM fiber
3.6 Alignment of a Laser Diode to a PM Fiber
3.7 Alignment of a PMF Patchcord
3.8 Aligning the connectors key to a main axis of a PM fiber
3.9 Measurement consideration
4 Remote Operation
4.1 Installing Software
4.1.1 Install NI Visa 4.2
4.1.2 Install Remote Control Application
4.1.3 Install Instrument Communicator
4.1.4 Install Firmware Upgrade Wizard
4.1.5 Install NI Instrument Drivers
4.2 Connect the ERM100
4.3 Remote Control Application
3
4
4
5
5
5
5
6
6
6
7
7
8
8
9
9
9
10
10
11
11
11
12
12
12
13
14
14
15
16
16
17
20
22
23
26
27
30
