SPIN RAPID ROLL-UP DOOR
USER'S AND INSTALLER'S MANUAL
7
v5.0
REV. 08/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPIN and is the answer not in the manual?

Questions and answers

Related Manuals for Motorline professional SPIN

Summary of Contents for Motorline professional SPIN

  • Page 1 SPIN RAPID ROLL-UP DOOR USER’S AND INSTALLER’S MANUAL v5.0 REV. 08/2022...

  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the 03. AUTOMATISM European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances in...
  • Page 3 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. Read all instructions carefully before beginning the installation/ WARNINGS FOR TECHNICIANS usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
  • Page 4 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation •...

  • Page 5: Package

    TECHNICAL SPECIFICATIONS Turning to the right will open the door and The SPIN rapid door is built with its own white lacquered aluminum profiles and is suitable for turning to the left will close. areas with medium air pressure, as it has 3 to 6 reinforcement struts.

  • Page 6: Dimensions - Normal Kit

    03. AUTOMATISM 03. AUTOMATISM DIMENSIONS - NORMAL KIT DIMENSIONS - TUNNEL KIT 195 (OLC) 368 (OLM) 530 (PM) 530 (PM) LVT-320 Wall Wall LEGENDA OLM • Motors side clearance Lateral Lateral guide guide OLC • Opposite side clearance PM • Minimum Lintel LVP •...

  • Page 7: Installation

    04. INSTALLATION INSTALLATION MAP 1 • 7 • 13 • Aluminum safe profile Motor Photocell fixation plate 2 • 8 • 14 • Photocell column Lateral Guides Connector Connections 3 • 9 • 15 • Motor cover Motor unlock lever Photocell 4 •...

  • Page 8: Safe Profile Fixation

    04. INSTALLATION SAFE PROFILE FIXATION POSITIONING SAFE PROFILE Apply the safe profile to the wall of the installation site, paying attention to the horizontal level and 85mm between the base of the support plate and the beginning of the passageway. The safe profile should be centered with the passageway.

  • Page 9: Lateral Guides And Control Board Fixation

    04. INSTALLATION LATERAL GUIDES AND CONTROL BOARD FIXATION APPLY LATERAL GUIDES Place the lateral guides by placing them on the inside of the support plates and against the wall. The tarpaulin must be inside the lateral guides so that it can always go up and down inside.

  • Page 10: Installation Tunnel Kit

    05. INSTALLATION TUNNEL KIT SAFE PROFILE FIXATION Safe profile completely leaning against the wall and ceiling. POSITION SAFE PROFILE Insert the safe profile into the tunnel and apply at the desired location for installation, taking into account the horizontal leveling. Based on the holes in the support plates, mark the locations for drilling.

  • Page 11: Lateral Guides And Control Board Fixation

    05. INSTALLATION TUNNEL KIT LATERAL GUIDES AND CONTROL BOARD FIXATION APPLY LATERAL GUIDES Place the lateral guides by placing them on the inside of the support plates and leaning against the wall. The tarpaulin must be inside the lateral guides so that it can always go up and down inside.

  • Page 12: Limit-Switches

    06. LIMIT-SWITCHES LIMIT-SWITCHES ADJUSTMENT • ADJUSTMENT • CONNECTIONS The ring 4 should activate the micro switch from below, and the ring 3 should activate the micro switch from above. CLOSE OPEN Manually place the door in the area you want for the opening slowdown. Turn the adjusting screw 4 until the limit switch ring 4 activates the corresponding microswitch.
