In this section, you can find information using your hub in charge or sync application. You can
also find information on managing your hub, changing port modes, connecting multiple hubs to
Your TS3-16 has inbuilt LEDs used to show the state of the ports or devices. These LEDs can be
configured to support your use case; this can be controlled either by using the API to send
Port is in charge mode and is profiling the device
Port is in sync mode and has a host connection
Port is in charge mode and the device has reached the
When the Hub is switched on and is not connected to a local host computer it is
automatically configured to charge devices using its intelligent charging algorithm. Connect the
Once the devices are connected, the algorithm will detect the highest charge rate allowable for
each attached device. Charging at the optimum rate (up to 2.4A) specified by the manufacturer
will commence once profiling is complete. Depending on the state of charge of the device
During profiling, the LEDs will flash red. Charging at the optimum rate specified by the
manufacturer (up to 2.4 Amps) will commence once profiling is complete. At this point, the red
LEDs will be constantly illuminated. Depending on the state of charge of the device attached,
profiling may take tens of seconds. Once the device is nearly fully charged, and the current
. draw falls below a set limit for a given period, the green LEDs will be illuminated
Page 11 of 39
Port is in charge mode and is charging
charged threshold

Using without connecting to host

devices to be charged to any of the available ports (not the Host Port) using

Using your TS3-16

. one host and using Cambrionix Software

LED Configuration

. commands directly or through separate software
. The default LED behaviour of the hub is below
Behaviour
. attached, this may take tens of seconds
5 .
5.0.1
Colour
Flashing Red
Red
Yellow
Green
. 5.1
. USB - compliant cables
TS3-16
