SETUP MODE, cont'd.
Step-by-Step Instructions,
cont'd.
• If the cursor does not behave as described, the LSS must be
adjusted.
• The value in the centre of the upper line shows the level of the LSS.
Select another level by pressing <Print> with the printhead
lifted.
EasyCoder 201 IIS:
Each time you press <Print>, the level will increase one step in
a loop of four levels (000-001-002-003-000-001-002-003-000....).
EasyCoder 401, 401 Linerless, 501S and 601S:
Each time you press <Print>, the level will increase 8 steps in a
loop between 0 and 127 (0-7-15-23-31-........-119-127-0–7....).
Keep trying until you find a level, that places the cursor as
described.
• When the adjustment looks right, lower and lift the printhead.
This will produce a TESTFEED, i.e. it will allow the printer feed
out one label, ticket, tag or piece of strip in order to adjust itself and
to allow you to check that the paper feed works correctly. At least
two TESTFEEDs should be produced before you go on.
• If you cannot make the LSS work correctly by following the
instructions above, you may – as a last resort – need to adjust the
potentiometer on the CPU board, see the Technical Manual of the
printer model in question.
• Try different combinations of potentiometer settings and LSS
levels until the cursor is positioned correctly.
• When you are satisfied that the LSS is set up correctly, lower the
printhead and press <Print>. That will set the LSS and take you
to the part of the Setup Mode, where you can view all setup
parameters, that is just as if you had entered the Setup Mode with
the printhead lowered:
CONTRAST
5
• Now you can check all current setup values (except the LSS
adjustment and the printhead resistance), one after the other, by
pressing <Print> with the printhead lowered. The parameters
are organized in a loop so you can step through them over and over
again (see the overview on next page).
If you want to change any of these setup parameters, you must
use a setup file (see SETUP statement in the Intermec Fingerprint
6.13 Reference Manual) or use the Terminal Setup in Intermec
Shell.
• To leave, lift the printhead and press <Print>. This will take you
back to the Intermec Shell program.
