Connectors
Connector
DCIN1
DP1_HDMI2
UL2
HDMI1
LAN1
USB31
AUDIO1
USBC1/USBC2
SATA1
SATAPWR
JW_FPB1 (backside)
CPUFANB1(backside) CPUFAN Wafer
Headers
Header
SMBUS
FP_USB21
COM1
GPIO
12V DC–in System Power Jack
Top: Display Port Connector
Bottom: HDMI Connector
Top: 2.5Gbps RJ-45 LAN Port Connector
Bottom: USB 3.1 (Gen.2) Port Connector
HDMI Connector
2.5Gbps RJ-45 LAN Port Connector
Top: USB 2.0 Port Connector
Bottom: USB 3.1 (Gen.2) Port Connector
Line-Out/MIC Combo Connector
USB 3.1 (Gen.2) Type-C Port Connector
SATAIII Port Connector
SATA HDD Power out Wafer
Front Panel Power Wafer
Name
SMBUS Header
USB 2.0 Port Header
Serial Port Header
GPIO Header
6
Name
Description Pitch
5-pin Block 2.0mm
9-pin Block 2.0mm
9-pin Block 2.0mm
10-pin Block 2.0mm
