Sywell - 4 Door Mirrored Robe
Assembly Instructions -
Dimensions
Width - 136.5cm
Depth - 49.5cm
Height - 175.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
615/8482
615/8468
615/8475
615/8437
615/8444
615/8451
MADE IN
BRITAIN
Issue 5 - 05/06/13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Sywell 615/8482
Summary of Contents for Argos Sywell 615/8482
- Page 1 Sywell - 4 Door Mirrored Robe Assembly Instructions - 615/8482 Please keep for future reference 615/8468 615/8475 615/8437 615/8444 615/8451 Dimensions Width - 136.5cm Depth - 49.5cm MADE IN Height - 175.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 5 - 05/06/13...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 78kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Upright Plain Door 5 Mirror Door (D2377A) (D2378A) (D0943B)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the upright Important: The hinge plates used in this step are in the bag Finished marked as AHP0826. front edge Fit 3 hinge plates onto the upright...
- Page 6 Assembly Instructions Step 3 Fit the top to the upright Attach the top to the upright using 2 screws Finished front edge Finished front edge Step 4 Fit the base to the upright Attach the base the upright using 2 screws p l a i n c...
- Page 7 Assembly Instructions Step 5 Prepare the right side Important: The hinge plates used in this step are in the bag marked as AHP1546. Fit 3 hinge plates onto the right side , making sure that the slot is facing towards the finished front edge.
- Page 8 Assembly Instructions Step 7 Prepare the plinth Plain chipboard Tap 2 wooden dowels surface into the plinth Step 8 Fit the plinth Attach the plinth the right side using screw Plain chipboard surface...
- Page 9 Assembly Instructions Step 9 Prepare the left side Important: The hinge plates used in this step are in the bag marked as AHP1546. Finished Fit 3 hinge plates onto front edge the left side , making sure that the slot is facing towards the finished front edge.
- Page 10 Assembly Instructions Step 11 The measurement from top corner X to bottom corner X must be Fit back panels equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 11 Assembly Instructions Step 12 Fit the hanging rails Push the 2 hanging rails into the rail holders fitted to the left side , right side both surfaces of the upright...
- Page 12 Assembly Instructions Step 13 Prepare the plain doors Important: The 6 hinges used in this step are in the bag marked as AHP1546. Push fit 3 hinges into each plain door Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees...
- Page 13 Assembly Instructions Step 15 Fit the mirror doors and handles Note: The easiest way to attach each mirror door to the upright to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
- Page 14 Assembly Instructions Step 16 Fit the plain doors and handles Note: The easiest way to attach each plain door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
- Page 15 Assembly Instructions Step 17 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 16 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2630...
