New Pagnell Desk
Assembly Instructions -
Dimensions
Width - 100cm
Depth - 48.5cm
Height - 71.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Please keep for future reference
622/1168
618/7202
606/9447
Version 1 Date: 09/11/16
Advertisement
Related Manuals for Argos HOME New Pagnell 622/1168
Summary of Contents for Argos HOME New Pagnell 622/1168
- Page 1 Width - 100cm Depth - 48.5cm Height - 71.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 1 Date: 09/11/16...
- Page 2 IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE • Argos Ltd. MK9 2 NW. • This product is intended for • Assembly of this product must children in the age 6 or above.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Top support (58.5 x 11cm) Finished front edge Bottom support (58.5 x 11cm)
-
Page 4: Tools Required
Components - Fittings Note: The quantities below are the correct amount to complete the assembly. In some cases mor may be supplied than are required. (This Screw is included in the bag of runner) Runner x 6 30mm Dowel x 13 12mm Screw x 18 14mm Screw x 4 39mm Locking pin x 22... - Page 5 Assembly Instructions Step 1 Middle hole Attaching runners Position Runners front edge of the Right side panel 1.7cm Slide top of the Runners on the Right Runners side panel Note: The front part of the runner should be approximately 1.7cm from the front edge of the Pilot holes for panel.
- Page 6 Assembly Instructions Step continued Middle hole Position Runners front edge of the Middle panel Slide top of the Runners 1.7cm Runners on the Middle panel Note: The front part of the runner should be Finished approximately 1.7cm front edge from the front edge of the panel.
- Page 7 Assembly Instructions Step 2 Fitting dowels and locking pins Insert Dowels into the Left side panel Screw Locking pins into the Left side panel Insert locking pins Note: as far as shown. Do not over tighten. Insert Dowels into the Top support Bottom support Front support Back support...
- Page 8 Assembly Instructions Step 3 Attaching plastic supports Plastic supports onto the Front panel Front panel onto the Front support Step 4 Attaching bottom panel and back back edge support Position Front support and Back support onto the Right side panel Insert Locking nuts into the Front support and Back support...
- Page 9 Assembly Instructions Step 5 Attaching middle panel Middle panel onto the back edge unit. Use Screw covers cover the screw heads. Top support Bottom support onto the Middle panel Finished front edge...
- Page 10 Assembly Instructions Step 6 Attaching left side panel Position Left side panel back edge onto the unit. Insert 2 Locking nuts into the Top support and Bottom support Use a screwdriver to turn Locking nuts clockwise to lock. Step 7 Attaching table top Screw Locking pins into the Table top...
- Page 11 Assembly Instructions Step 8 Fixing back panel Attach Back panel onto the unit using Nails Important: The unit MUST be ‘square’ when back is attached. Step 9 Drawer assembly Screw Locking pins into 4 holes shown on back of the Drawer front Insert Locking pins Note: as far as shown.
- Page 12 Assembly Instructions Step 9 - continued Fix Drawer right side onto the Drawer front Insert 2 Locking nuts into the holes (they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock. Insert 2 Locking nuts into the holes (they will only insert one way).
- Page 13 Assembly Instructions Step 10 Large drawer assembly Screw Locking pins into 4 holes shown on back of the Large drawer front Insert Locking pins Note: as far as shown. Do not over tighten. Fix Large drawer left side onto the Large drawer front Fix Large drawer right side...
- Page 14 Assembly Instructions Step 10 - continued Place a small amount of Glue into the groove Large drawer back Position the Large drawer back onto the unit using Screws Step 11 Inserting large drawer With help, carefully stand desk upright. Warning: The Desk is heavy.
- Page 15 Note: Before use allow the glue to dry for 24 hours and make sure the unit is secure. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
