Verona Coffee Table

Assembly Instructions -

Dimensions

Width - 90cm

Depth - 45cm

Height - 41cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

609/5033

610/6812

issue 1 4/23/10
