TLX48
KVM Matrix Switch
PRODUCT MANUAL
Full 4K @ 60Hz Video and KVM Switching & Extension
Copyright Notice
Copyright © 2022. All rights reserved. Printed in the U.S.A.
All trademarks and service marks are property of their respective owners.
Thinklogical,
100 Washington Street
Milford, Connecticut 06460 U.S.A.
Telephone: 1-203-647-8700
Subject: TLX48 2RU KVM Matrix Switch Product Manual
Revision: B, May 2022
tl
https://www.thinklogical.com
Website:
www.facebook.com/ThinklogicalUSA
Facebook:
LinkedIn:
www.linkedin.com/company/thinklogical
www.youtube.com/user/thinklogicalNA
YouTube:
@thinklogical
Twitter:
Solutions in only 2RU of Rack Space
For both 6G and 10G
A BELDEN BRAND
2RU
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the thinklogical TLX48 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Belden thinklogical TLX48

Summary of Contents for Belden thinklogical TLX48

  • Page 1 Copyright Notice Copyright © 2022. All rights reserved. Printed in the U.S.A. All trademarks and service marks are property of their respective owners. Thinklogical, A BELDEN BRAND 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone: 1-203-647-8700 Subject: TLX48 2RU KVM Matrix Switch Product Manual Revision: B, May 2022 https://www.thinklogical.com...

  • Page 2: Table Of Contents

    Table of Contents Preface ..................................3 About Thinklogical ......................... 3 A BELDEN BRAND About this Product Manual ............................4 Active Links ................................4 Note and Warning Symbols ............................. 4 Referenced Documents ............................4 Class 1 Laser Information ............................4 Section 1: TLX System Features .........................

  • Page 3: Preface

    Thinklogical products are designed and manufactured in the USA and are certified to the ISO 9001:2015 standard. Thinklogical is headquartered in Milford, Connecticut and is owned by Belden, Inc., St. Louis, MO (http://www.belden.com). For more information about Thinklogical products and services, please visit https://www.thinklogical.com.

  • Page 4: About This Product Manual

    About this Product Manual Active Links This document contains active cross-reference links in the Table of Contents and for referenced pages throughout, shown in this format: [29], and for hyperlinks, shown in this format: link.format. For .pdf, point/click, for .doc: Ctrl/point/click. To return to the front of the document press Ctrl/Home. This product manual has four sub-divided sections to help you find specific topics and procedures.

  • Page 5: Section 1: Tlx System Features

    Section 1: TLX System Features The Logical Solution The TLX48 2RU is a 10G high-performance, modular, non-blocking Matrix Switch that supports full, uncompressed 4K video with full-color depth at 60Hz frame-rate for complete, end-to-end routing of video and peripheral signals over multi-mode or single-mode fiber-optic cable, all within a one- third reduction in weight and form factor from its predecessor.

  • Page 6: Design Features

    The TLX48 2RU Matrix Switch Design The modular approach of the TLX48 2RU 10G Matrix Switch (sometimes referred to as a Switch or Router) allows all critical system components to be hot-swappable, including Input/Output Cards, Power Supplies, Annunciator Module, Control Cards and pluggable optics (SFP+), thus minimizing down-time during reconfigurations, updates or failures.

  • Page 7: Product Compatibility

    Product Compatibility The TLX48 2RU is compatible with the following Thinklogical products: ® • Single & Multi-Mode TLX 10G KVM and Video Extenders (10G to 10G only) • Single & Multi-Mode Velocity/Q-Series 6G KVM and Video Extenders (6G to 6G only) •...

  • Page 8: The Control Cards

    The Control Cards The hot-swappable Control Cards (also referred to as Controllers) connect the TLX48 2RU to an External CPU. LAN Ports are available in either fiber-optic or copper RJ45 configurations. The RS-232 serial port may be used for third-party controller integration (such as Crestron, AMX or home-spun interfaces).
  • Page 9 The Network Interfaces A TLX48 2RU uses up to three IP addresses. The Primary Control Card uses address X and address X+100. The Back-up Control Card uses address X+1 and will take over address X in the event of a failure in the Primary Control Card.
  • Page 10 SNMP Support The TLX48 2RU can be monitored via SNMP Simple Network Management Protocol (supports version V2c and V3 USM). Please call our technical support staff at 1-203-647-8700 for downloadable MIB Management Information Base definition files. /etc/snmp/snmpd.conf Some entries in the SNMP configuration file ( ) that users typically modify are: •...

  • Page 11: The Fan Tray Module

    The Fan Tray Module The TLX48 2RU uses 3 DC fans located in one modular, hot-swappable fan tray designed for easy replacement without interrupting system functionality. The Fan Tray introduces air into the chassis through air baffles along the chassis side panel. This cools the horizontally mounted I/O Cards, the Control Cards and the backplane.

  • Page 12: The Input / Output Cards

    The Input / Output Cards The TLX48 2RU contains up to 2 horizontally-mounted I/O Cards. The hot-swappable Input/Output (I/O) cards provide in-service expansion capabilities in sets of 24 ports per I/O card, thus allowing re-configuration without interrupting signal processing. Each standard I/O card consists of one Transmit (T) and one Receive (R) optic per port. I/O Cards are available with LC-type fiber connectors and can be assembled with Single-mode or Multi-mode optics (SFP+).

  • Page 13: Tlx48 2Ru Technical Specifications

    TLX48 2RU Technical Specifications PHYSICAL Dimensions: Rack Size: EIA 19.00" (482.6 mm) Height: 2 RU - 3.50” (88.9 mm) TLX 48 2RU Depth: 12.50" (317.5 mm) Chassis Width: 17.47" (443.7 mm) Weight (fully loaded): 22.0 lbs. (10.0 kg) Shipping Weight: 27.0 lbs. (12 kg) Fiber Ports 24 x 24 min., 48 x 48 max., 1 LAN per Control Card (option) ENVIRONMENTAL Operating: 0°...

  • Page 14: Section 2: Set-Up & Installation

    Section 2: Set-Up & Installation Contents When you receive your Thinklogical TLX48 2RU KVM Matrix Switch, you should find the following ® items in the quantities specified in your order: • TLX48 2RU Chassis (includes one or two 2 Power Modules, 1 Fan Tray, up to 2 Input/Output Cards and one or two Control Cards) •...

  • Page 15: Connecting To The Tlx48 2Ru Matrix Switch

    Connecting to the TLX48 2RU Matrix Switch Thinklogical’s line of TLX, Velocity and Q-Series Extenders come in both multi-mode and single- mode fiber-optic cable versions. Thinklogical’s proprietary multiplexing technology combines video, audio and peripheral data on a single data stream for up to 80km over a single-mode fiber. The TLX48 2RU is compatible with the following Thinklogical products: ®...

  • Page 16: Pluggable Sfp+ Modules

    Redundancy and Network Requirements The simplest network connection is an isolated network with only the TLX48, the control server, and any control clients using static IP addresses. The TLX48 can be set to any of the above settings. The Control Server must be at 192.168.13.9, and the Control Clients can then be set to any other addresses in the 192.168.13.X subnet.

  • Page 17: Lc-Type Fiber-Optic Cable

    LC-Type Fiber-optic Cable Installing Fiber-optic Cable OPTICAL OUTPUT PORT (Transmit) The TLX switching matrix connects any SFP’s optical output port (Transmit) to any other SFP’s OPTICAL INPUT PORT (Receive) optical input port (Receive) with LC-type Connectors. Requirements Thinklogical recommends LC-ty[e SX+ Laser Enhanced (50µm) fiber for the TLX48 2RU KVM Matrix Switch and Extension System.
  • Page 18 TLX Extender Fiber-Optic Cable Configurations Single Video Dual Video Note: On Dual Video models, SFPs 1 & 2 are Video 1 and SFPs 3 & 4 are Video 2.

  • Page 19: Routing Thinklogical Extenders Through The Tlx48 2Ru

    Routing Thinklogical Extenders through the TLX48 2RU Comprised of a fiber-in, fiber-out matrix switch and fiber-optic KVM Transmitter and Receiver Extenders, this complete system provides transparent and secure routing, switching and extension of video and high-speed data peripherals to remote destinations with ease. Matrix Switch Transmit / Receive Concept Connecting to the Receiver The Receiver serves as the Destination (desktops, theaters, conference rooms, editing suites, control...
  • Page 20 Routing Thinklogical TLX Extenders through the TLX48 2RU ® Connecting to a Control CPU The TLX48 2RU is controlled via a dedicated external Control CPU. This allows for customization as well as ease of control and administration. Access is provided via fiber-optics, CATx or serial RS-232. Note: The Control CPU (Computer) is supplied separately.

  • Page 21: Operating System Default Users / Passwords

    Operating System Default Users / Passwords TLX48 2RU Matrix Switch Operating System: Centos 7 Installed on V5.09.XX • OS default username/password • centos/temppwd • root/root (cannot remote into OS as root user) Linux Command Console (Console) • Baud Rate: 115200 •...

  • Page 22: Safely Remove An Active Control Card Or Shut-Down The System

    Safely Remove an Active Control Card or Shut-down the System During normal, non-maintenance operation, the Primary Control Card (CTRL 1, lower card) should always be the Active controller for the system. However, there may be times when other conditions temporarily exist, such as during maintenance, updates, repairs, etc.

  • Page 23: How To Remove And Replace Modules

    How to Remove and Replace Modules How to Remove and Replace an Input / Output Card Note: No shutdown is required prior to installing/replacing Input / Output Cards. Remove any connected fiber-optic cables. Turn the card’s two thumbscrews counterclockwise until they disengage from the chassis. Pull the I/O Card straight out using both handles located at the outer edges of the module.

  • Page 24: How To Remove And Replace A Fan Tray

    How to Remove and Replace a Fan Tray The TLX48 2RU uses three DC fans to move air horizontally through the enclosure. Always replace a failed Fan Tray immediately. Do not allow the unit to run for more than 90 seconds before installing a working Fan Tray. Be sure to not block the air vents on the sides of the unit and leave at least 2”...

  • Page 25: How To Remove And Replace An Annunciator Module

    How to Remove and Replace an Annunciator Module Note: No shutdown is required prior to installing/replacing the Annunciator Module. Remove any external connections (alarm). Turn the module’s two thumbscrews counterclockwise until they disengage from the chassis. Pull the module straight out using the handle. Do not pull on the thumbscrews when removing the module –...

  • Page 26: Section 3: Regulatory & Safety Requirements

    European Union Declaration of Conformity Manufacturer’s Name & Address: Thinklogical, A BELDEN BRAND 100 Washington Street Milford, Connecticut 06460 USA Thinklogical’s products comply with the requirements of the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU, the WEEE Directive 2012/19/EU and carry the marking accordingly.

  • Page 27: Supplementary Information

    Electromagnetic Immunity EN 55024:2011+A1 CENELEC EN 55032:2015 EN 61000-3-2:2000 Harmonics EN 61000-3-3:2008 Flicker EN 61000-4-2:2009 Electro-Static Discharge Test EN 61000-4-3:2006 A1:2008, A2:2010 Radiated Immunity Field Test EN 61000-4-4:2004 Electrical Fast Transient Test EN 61000-4-5:2006 Power Supply Surge Test EN 61000-4-6:2009 Conducted Immunity Test EN 61000-4-11:2004 Voltage Dips &...

  • Page 28: Section 4: Thinklogical Support

    1-203-647-8700 and let us help. If you need to write us or return a product, please use the following address: Please include the Return Merchandise Authorization number: Thinklogical, A BELDEN BRAND 100 Washington Street Milford, CT 06460 USA Attn: RMA#...

  • Page 29: Appendix A: Tlx48 2Ru Quick Start Guide

    APPENDIX A: TLX48 2RU Quick Start Guide thinklogical TLX48 2RU KVM Matrix Switch Product Manual Rev. B, May 2022...

  • Page 30: Appendix B: Sd Card Replacement For Tlx48 2Ru Controller Cards

    APPENDIX B: SD Card Replacement for TLX48 2RU Controller Cards This procedure assumes a normally operating TLX system that is using both a Primary and a Back-up Controller Card. upstream.csv Note: If Partitioning, Restricted Switching or P2P is being used, copy the file /var/local/router from the appropriate...
  • Page 31 Set or Change the Date, Time and Time Zone Having the clocks set on system devices ensures that the log entries will have accurate timestamps if the system needs troubleshooting or the logs need to be examined. 1. Log into the device as root. 2.

  • Page 32: Appendix C: Secure Applications

    APPENDIX C: Secure Applications TLX Matrix Switch Control When used in a secure application, the Matrix Switch and External Computer (server) used to manage the system must be in a physically secure environment to which only trusted administrators have access. Similarly, the server used to manage the Matrix Switch must be physically protected and have suitable identification/authentication mechanisms to ensure that only trusted administrators have access.
  • Page 33 Restricted Switching Restricted Switching provides multiple levels of security classification domains on the same Matrix Switch. Each destination must ensure that no unauthorized content is displayed or accessed. Therefore, every input and output must be prioritized. Priorities can range from 1 to the total number of ports in the Matrix Switch. An output can connect to an input with a priority greater than, or equal to, its own.
  • Page 34 To verify the system’s Restricted Switching policy, Thinklogical recommends the following: 1) Review the daemon.log file on the active Controller Card and correct any errors in the Restricted Switching Table before implementing multiple levels of security classification domains on the same Matrix Switch.
  • Page 35 Restricted Switching with TLX, VX and MX Matrix Switches Restricted Switching Priority Scheme The following example shows a priority scheme for four levels of security managed by one TLX Matrix Switch: Restricted switching is configured via an upstream.csv file loaded into the Matrix Switch.
  • Page 36 Partitioning Partitions allow TLX, VX and MX Matrix Switch sources and destinations to be segregated. Therefore, destination workstations will only receive signals that are transmitted from source computers in the same partition. In addition, it is impossible for a source computer to be inadvertently routed outside of its designated partition as the signals will not be transmitted.
  • Page 37 At system power up, after initial boot-up, the Primary Controller Card will only evaluate its Partition Table (upstream.csv file) once upon becoming active. The Back-Up Controller Card will NOT evaluate its Partition Table (upstream.csv file) at initial boot-up, but it will when a switchover occurs from Primary Active to Back-Up Active.
  • Page 38 Partition Switching is disabled when Partition Table files are removed. By default, when there are no Partition Table files, all ports not listed will default to partition 1. All Switches are shipped without Partition Table files stored on the Controller Card and therefore do not restrict any connection. Administration Access There are two methods by which the administrator can access the Switch Controller Configurations: 1.
  • Page 39 Secure Application Examples The Diagram on pg. 41 shows the TLX48 2RU Matrix Switch in a secure application. The highly secure components are described as the Red Network and the other, lower security components are described as the Black Network. The Red Network, containing the computers (sources), is shown in a physically secure environment along with the TLX Matrix Switch, the computer server used to manage the Switch, and the Network Hub.
  • Page 40 thinklogical TLX48 2RU KVM Matrix Switch Product Manual Rev. B, May 2022...
