ISO Standard
Hydraulic Cylinder
CHS
Series
Reduced projection area:
CHSD/Basic
CH2
Maximum weight: no more than
50 52
∗
% or
(CHSD) (CHSG)
∗
Compared to CH2 series, the tie-rod type cylinder of same size.
Cylinder with built-in cover and
mounting bracket allows easy
disassembly and assembly.
Conforming to ISO 10762 (JIS B 8367-5:2002)
CHSD
Series
Ø 40, Ø 50, Ø 63, Ø 80, Ø 100
1
Nominal pressure 10 MPa /16 MPa
76 76
%
or less
∗
% of CH2 series
10 MPa
/
Reduced overall length
A +
Stroke
A +
Stroke
Overall length (A size)
Tube size
[mm] CHSD CHSG
-
153
32
163 184
40
177 200
50
199 217
63
225 251
80
260 275
100
Conforming to ISO 6020-2 (JIS B 8367-2:2002)
CHSG
Series
Ø 32, Ø 40, Ø 50, Ø 63, Ø 80, Ø 100
CHSD/CHSG
CH2
CH2
207
212
231
257
295
325
16 MPa
/
