BRIDGED MONO INSTALLATION
STEREO
CASSETTE DECK
AMP MODE
BRIDGED
INPUT
AVIS
CHANNEL 2
RISQUE DE CHOC
OC03 OC03
ELECTRIQUE NE PAS
MODEL NO. R500 PLUS
BALANCED
OUVRIR.
REFERENCE AMPLIFIER
0dBm
RATED OUTPUT 250W/CH @4Ω STEREO
RATED OUTPUT 500W @8Ω BRIDGED MONO
AMP MODE
S N
STEREO BRIDGED
~
AC INPUT: 230V 50Hz,480W
FUSE: T5AL/250V
MIC
SPEAKER
OUTPUT
CAUTION
CHANNEL 2 CHANNEL 1
TO REDUCE THE RISK
OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
TO REDUCE THE RISK OF
~ ~
(4 8 ) (4 8 ) FIRE REPLACE ONLY WITH
SAME TYPE FUSE.
UTILISER UN FUSIBLE
DE RECHANGE DE
MEME TYPE.
~ ~
(4 8 ) (4 8 )
BRIDGED
MONO
(8 ~16 )
