  • Page 1 OPERATING MANUAL R E M O T E A M P L I F I E R W I T H Z O N E SELECTOR RM-916...

  • Page 2: Unpacking And Installation

    UNPACKING AND INSTALLATION Although it is neither complicated to install nor difficult to operate your power Amplifier, a few minutes of your time is required to read this manual for a properly wired installation and becoming familiar with its many features and how to use them.

  • Page 3: Operating Procedure

    • MIC BROADCASTING Easy to use, highly sensitive condenser type MIC for clear broadcasting. • AUXILIARY SIGNAL INPUT Auxiliary signal input for Cassette Deck or Tuner makes the RM-916 an ideal remote piece of equipment for broadcasting background music. OPERATING PROCEDURE 1.

  • Page 4: Front Panel Controls

    SPEAKER CONTROL MIC INPUT 10 11 12 13 14 15 16 POWER 10 11 12 13 14 15 16 CHIME SPEAKER CONTROL LINE OUT RM-916 POWER REMOTE AMPLIFIER WITH ZONE SELECTOR OUTPUT LEVEL CHIME CH 1 CH 2 CH 3...
  • Page 5 10. ALL CALL LED Visual indication showing that all the sixteen loudspeaker zones are selected. 11. CHIME SWITCH This switch, when pressed, will output a four tone pre-announcement chime to the selected loudspeaker zone(s). 12. CHIME SWITCH LED This LED will illuminate when the chime switch is pressed. 13.
  • Page 6 1. Ensure that power is switched off before installation and before any wiring is connected to the equipment. 2. Site the equipment in well ventilated places and avoid places of high humidity. 3. Whenever possible, fit Inter-M MIC model CM-916. If a Phantom powered MIC is to be used, we recommend that it operates on +5V DC.
  • Page 7 5A MAX SWED 1 (2000W) SWED 2 (2000W) BATTERY AC INPUT AC FUSE INPUT 230V/50Hz,217VA 2A/250V UNSWED (700W) DC FUSE 7A/250V SWED 3 (2000W) RM-916 (1) DC 24V IN AUX IN DIGITAL VOLUM POWE POWE PRES MUTE TUNER PT-9107 PT-910 POWER...

  • Page 8: Block Diagram

    BLOCK DIAGRAM...

  • Page 9: Specifications

    SPECIFICATIONS *0dB=0.775Vrms ELECTRICAL • Output Level/Impedance ......................+4dB/600 , BAL • Input Sensitivity/Impedance MIC..........................–60dB/600 , BAL AUX ........................–20dB/10K , UNBAL • Frequency Response (–3dB) ....................... 20Hz–20KHz • T.H.D............................Less than 0.2% • S/N............................Better than 60dB • Speaker Control Terminal & Switch......................16 CH GENERAL •...
  • Page 10 NOTE...
