Inter-m RM-916 Brochure & Specs

RM
- 916
REMOTE AMPLIFIER WITH ZONE SELECTOR
FEATURES
ZONE CONTROL CIRCUITS
Speaker zones can be selected individually by means of
the CHANNEL switches or altogether using the ALL
CALL switch.
ANNOUNCEMENTS BY MICROPHONE
Unobtrusive and easy to use condenser type microphone
which is highly sensitive and reproduces high clarity
speech. Paging is initiated by pressing the TALK switch.
PRE-ANNOUNCEMENT CHIME
A four tone chime is incorporated for pre-announcement
purposes. It is initiated by pressing the CHIME switch.
AUXILIARY INPUT FOR INCREASED VERSATILITY
The auxiliary input can be used for a wide range of signal
sources such as cassette deck or tuner, making it the
ideal solution for broadcasting background music or
radio to the power amplifier.
LED OUTPUT LEVEL INDICATION
The ten segment LED barograph display indicates the
instantaneous signal output level of the amplifier.
Any excessive input to the amplifier can therefore be
monitored and adjusted as necessary.
SPECIFICATION
ELECTRICAL
Output Level/Impedance ..................1.2V±200mV, BAL
Input Sensitivity/Impedance ......MIC: -60dB/600Ω, BAL
.............................................AUX: -20dB/10kΩ,UNBAL
Frequency Response(±3dB) ..........MIC: 100Hz~15kHz
.........................................................AUX: 80Hz~18kHz
T.H.D ............................................MIC: Less than 0.5%
.....................................................AUX: Less than 0.2%
S/N .............................................MIC: Better than 50dB
..................................................AUX: Better than 55dB
Speaker Control Terminal & Switch.....................16 CH
GENERAL
Power Source ...............................................
Weight ..............................
Dimensions ........................
*0dB=0.775Vrms
DC 24V
1.2kg(Without Microphone)
245(W)x60(H)x205(D)mm
