2.3 Wall mounting
1
Remove the thermostat cover as shown in the
picture. If there are batteries inside, remove them.
3
Separate the front part from the back part in
the direction shown above.
5
Using the hinges, fold the back and front
covers by moving as shown in the picture
6
E901RF FULL USER MANUAL
above.
2
Use a screwdriver to push the plastic tabs in as
shown in the figure until you feel resistance,
and tilt the front part of the housing.
4
Then fix the back cover to the wall using the
supplied mounting screws and the holes
provided (see red arrows).
