About the LED Indicators

The PSE-McBasic features four diagnostic LEDs. The diagram below
shows the location of the LEDs.
The LED functions are:
LNK/ACT
ZERO CRNT Glows red when no device is connected to the PSE-
OVER CRNT Glows red when an overcurrent condition lasts for more
PWR FAIL
PWR
AN
TX LL
FX LL
FA
FiberAlert will not function when single-strand fiber is connected.
4W
7W
15.4W
FX LNK/ACT Glows green when a link is established on the fiber port
Glows amber when a twisted pair link is established and
blinks when activity is detected on the UTP port.
McBasic or when the device is NOT a valid PD. The
LED is off when the PSE-McBasic detects a valid PD.
than 60 ms after power up and/or when an over tem-
perature condition occurs.
Glows red when an overcurrent or internal fault is
detected within the PSE-McBasic PoE circuit.
Glows green when the PSE-McBasic is powered up.
Glows green when Auto-Negotiation is enabled.
Glows green when TX LinkLoss is enabled.
Glows green when FX LinkLoss is enabled.
Glows green when FiberAlert is enabled and blinks when
a FiberAlert situation occurs (i.e. the loss of one strand of
fiber).
Glows green when Powered Device consumes 3.84
watts to 4 watts of power (CLASS1 PD).
Glows green when Powered Device consumes 6.49
watts to 7 watts of power (CLASS2 PD).
Glows green when Powered Device consumes 12.95
watts to 15.4 watts of power (CLASS0 PD).
and blinks when activity is detected on the port.
