IV. SPECIFICATIONS AND COMPONENTS
To operate the GO-A8-PW effectively the user should be familiar with each of the Gate
Opener's components. See Figure 1 for a Component layout, and the separate
WORKMASTER GO-A8-PW Gate Opener Maintenance & Parts Manual
(PN: 10-00067).
The GO-A8-PW Pneumatic Hopper Car Gate Opener consists of a heavy-duty
reversible impact motor, self-closing lever control mechanism and a Rolling Cart. The
GO-A8-PW Opener is portable, rugged and capable of operating in the toughest
environment. Under recommended operating conditions and with regular maintenance,
the GO-A8-PW Opener can generate up to 13,000 ft./lbs. torque. The Impact Motor is
air driven and requires a source of clean, dry compressed air for operation.
Every user should be aware of the technical specifications and operating characteristics
shown below in Table 1.
Table 1: Technical Specifications
CHARACTERISTICS
Frame Dimensions
Working Area Required
Working Torque Range
CFM/PSI Free Speed
CFM/PSI Impacting
Retainer Type
Weight
Free Speed
Air Inlet
Tire Size
Anvil Size
Hose Size
Lubrication
PH: 866.476.9217
GO-A8-PW
33" x 42" x 45"
308 Lbs (Shipping 460)
8 – 10 Ft Minimum – Site Specific
1500 RPM
1000 – 13000 Ft-Lbs
150 @ 85 PSI
114 @ 85 PSI
1" NPTF
400 x 8 Solid Polyurethane
1-1/2"
Socket Pin w/ O-Ring
1" ID
Air Tool Oil
