IV. SPECIFICATIONS AND COMPONENTS
To operate to GO-A13-HA effectively the user should be familiar with each of the Gate
Opener's components. See Figure 1 for a Component Layout, and the separate
WORKMASTER GO-A13-HA Gate Opener Maintenance & Parts Manual
(PN: 10-00069).
The GO-A13-HA Pneumatic Hopper Car Gate Opener consists of a heavy-duty
reversible impact motor, self-closing lever control mechanism and a Rolling Cart. The
GO-A13-HA Opener is portable, rugged and capable of operating in the toughest
environment. Under recommended operating conditions and with regular maintenance,
the GO-A13-HA Opener can generate up to 13000 ft./lbs. torque. The Impact Motor is
air driven and requires a source of clean, dry compressed air for operation.
Every user should be aware of the technical specifications and operating characteristics
shown below in Table 1.
Table 1: Technical Specifications
CHARACTERISTICS
Frame Dimensions
Handle Width
Working Area Required
Working Torque Range
Free Speed
CFM/PSI Free Speed
CFM/PSI Impacting
Inlet Coupling
Wheel Assembly
Anvil Size
Lubrication
Retainer Type
Hose Size
Height Adjustment
Weight
Universal Style w/ Safety Lock Pin
16" Dia w/ 4.80 / 4.00 – 8" Flat-Free
Solid Polyurethane w/ ribbed tread
Pneumatic Adjustments 10" – 24"
PH: 866.476.9217
GO-A13-HA
40"L x 42"W x 44"H
29"
361 Lbs (Shipping 520 Lbs)
8 -10 Ft
1000 – 13000 Ft-Lbs
1500 RPM
148 @ 85 PSI
114 @ 85 PSI
1-1/2"
Air Tool Oil
Socket Pin w/ O-Ring
1" ID
