IV. SPECIFICATIONS AND COMPONENTS
To operate to GO-A8-PW effectively the user should be familiar with each of
the Gate Opener's components. See Figure 1 for a Component layout, and
Appendix A for a breakdown of the Impactor and the list of Part Numbers.
The GO-A8 Pneumatic Hopper Car Gate Opener consists of a heavy-duty
reversible impact motor, self-closing lever control mechanism and a Rolling Cart.
The GO-A8 Opener is portable, rugged and capable of operating in the toughest
environment. Under recommended operating conditions and with regular
maintenance, the GO-A8 Opener can generate up to 13000 ft./lbs. torque. The
Impact Motor is air driven and requires a source of clean, dry compressed air for
operation.
Every user should be aware of the technical specifications and operating
characteristics shown below in Table 1.
Table 1: Technical Specifications
CHARACTERISTICS
Length
Width
Height
Weight
Working Area Required
Free Speed
Working Torque Range
CFM/PSI Free Speed
CFM/PSI Impacting
Air Inlet
Tire Size
Anvil Size
Retainer Type
Hose Size
Lubrication
GO-A8-PW
33"
42"
45"
308 Lbs
8 – 10 Ft Minimum – Site Specific
1500 RPM
1000 – 13000 Ft/Lbs
150 @ 85 PSI
114 @ 85 PSI
1" NPTF
400 x 8 Solid Polyurethane
1-1/2"
Socket Pin w/ O-Ring
1" ID
Air Tool Oil
3
